Signal System NTSC/PAL
DVD/VCR shared output jacks VIDEO jack: RCA Pin-jack
AUDIO jack: RCA Pin-jack
DVD output jacks VIDEO jack: S-Video jack
Component Y jack: RCA Pin-jack
Component P
B jack: RCA Pin-jack
Component P
R jack: RCA Pin-jack
AUDIO jack: RCA Pin-jack
DIGITAL AUDIO IF: Coaxial digital
AUDIO output jack: RCA Pin-jack
VIDEO input jacks VIDEO jack: RCA Pin-jack
AUDIO jack: RCA Pin-jack
Video recording system Two rotary head helical scan system, VHS, Hi-Fi
Video signal PAL: PAL System-B/G, I, D/K, M (Playback/Recording)
SECAM: MESECAM System B/G, D/K, K1 (Playback/Recording)
NTSC: NTSC4.43 (Playback/Recording)
NTSC:
NTSC System M (NTSC 3.58) (Playback/Recording)
Recording/playing time 720 minutes max. with E-240 tape (PAL)
480 minutes max. with T-160 tape (NTSC)
Tape width 12.7mm
Tape speed (PAL) (SP) 23.39mm/sec
(LP) 11.70mm/sec
(EP) 7.80mm/sec
(MESECAM) (SP) 23.39mm/sec
(LP) 11.70mm/sec
(NTSC) (SP) 33.35mm/sec
(LP) 16.67mm/sec (Playback only)
(EP) 11.12mm/sec
Antenna 75 ohm unbalanced
Receiving channel
VHF: 1A–E12 (C1–C12), UHF: E21–E69 (C13–C57),
European CATV: S1–S41
VHF: US AIR 2–13, UHF: US AIR 14–79, CATV: 2 to W+84
VHF: JAPAN 1–12, UHF: JAPAN 13–62
VHF: AU 0–13, UHF: AU 28–69 [DV-NC70X only]
NICAM format NICAM-I, B/G, D/K
IGR stereo format IGR-B/G, D/K
RF converter output signal E21–E69 (adjustable), US AIR 26–38 (adjustable),
JAPAN 25–37 (adjustable). [DV-NC70W/70 only]
AU 28 - AU69 (adjustable). [DV-NC70X only]
DVD/VCR shared Video output Output level: 1 Vp-p (75Ω)
Component color output Y output level: 1 Vp-p (75Ω)
P
B output level: 0.525 Vp-p (75Ω)/75% color
P
R output level: 0.525 Vp-p (75Ω)/75% color
S video output Y output level: 1 Vp-p (75Ω)
C output level: 0.3 Vp-p (75Ω)
Audio output Output level: 2 Vrms (1 kHz, 0 dB)
Video signal horizontal resolution 500 lines
S/N ratio 60 dB
Audio signal frequency characteristics
For DVD linear PCM playback:
4 Hz to 22 kHz (48 kHz sampling)
4 Hz to 44 kHz (96 kHz sampling)
CD playback: 4 Hz to 20 kHz (JEITA)
S/N ratio CD: 96 dB, 1 kHz (JEITA)
Dynamic range DVD linear PCM: 96 dB (JEITA)
CD: 96 dB (JEITA)
Total harmonic distortion ratio CD: 0.006% (JEITA)
Pickup Wave length: 650 nm (DVD) / 780nm (CD)
Laser output: Max. 0.7 mW
Operating temperature 5°C to 35°C
Storage temperature –20°C to 55°C
Power supply 110 V to 240 V AC, 50/60 Hz [DV-NC70W/70 only]
240 V AC, 50 Hz [DV-NC70X only]
Power consumption 23 W
Dimensions 430 mm × 93.5 mm × 356 mm (W × H × D)
Weight 4.8 kg
Specifications are subject to change without notice.
Weight and dimensions are approximate.
Specifications
INPUT/OUTPUT
JACKS
VCR
DVD
[
DV-NC70W/70 only
]
