1-11-4
E9656TS
Ye s
Ye s
Ye s
Ye s
No
No
No
No
FLOW CHART NO.14
The fluorescent display tube does not light up.
Is 5V voltage supplied to Pin(6, 24) of IC571?
Is approximately -24V to -28V voltage supplied to
Pin(15) of IC571?
Is there approximately 500kHz oscillation to
Pin(26) of IC571?
Are the filament voltage applied between (1)
and (24) of the fluorescent display tube?
Also negative voltage applied between these pins
and GND?
Replace the fluorescent display tube.
Check the EV+5V line and service it if defective.
Check the -FL line and service it if defective.
Check R595, IC571 and their periphery, and
service it if defective.
Check the power circuit, D023, D024, C029 and
their periphery, and service it if defective.
No
Ye s
Check D022, C028 and their periphery, and
service it if defective.
FLOW CHART NO.13
P-ON+3.3V is not outputted.
Is 4V voltage supplied to Pin(1) of IC1503?
Replace IC1503.
No
Is 4V voltage supplied to Pin(1) of IC1504?
FLOW CHART NO.12
P-ON+2.5V is not outputted.
Replace IC1504.
Check D022,C028 and their periphery, and service
it if defective.
Ye s
DVD-P-ON+5V is not outputted.
FLOW CHART NO.11
Is 5V voltage supplied to the collector of Q101?
No
Ye s
Check Q101 and their periphery, and
service it if defective.
Check D015, D016, C017, C019, L012 and their
periphery, and service it if defective.
To Next Page
