1-11-5
E9656TS
2. DVD Section
Ye s
Ye s
No
No
FLOW CHART NO.1
The key operation is not functioning.
Are the contact point and the installation state of
the key switches normal?
Is the control voltage normally inputted into
Pins(85, 86) of IC501?
Re-install some key switches correctly or
replace some key switches.
Check the key switches and their periphery, and
service it if defective.
Replace IC501.
Ye s
FLOW CHART NO.3
The disc tray cannot be opened and closed. (It can be done using the remote control unit.)
Is the normal control voltage inputted to Pin(85) of
IC501?
Refer to "FLOW CHART NO.1" <The key
operation is not functioning.>
Refer to "FLOW CHART NO.4" <The disc tray
cannot be opened and closed.>
Replace the "OPEN/CLOSE" button (SW615).
No
FLOW CHART NO.2
Replace the RS501 (remote control receiver).
Or replace remote control unit.
Check the line between the RS501 (remote
control receiver) and the Pin(5) of IC501, and
service it if defective.
Replace IC501.
Is the "L" pulse sent out from Pin(1) terminal of
the RS501 (remote control receiver) when the
remote control unit is activated?
Is the "L" pulse signal supplied to the Pin(5) of
IC501?
Ye s
Is 5V voltage supplied to the Pin(3) terminal of
the RS501 (remote control receiver)?
Ye s
Ye s
No
Check AL+5V line and service it if defective.
No
No
No operation is possible from the remote control unit. (
Operation is possible from the unit.)
To Next Page
