ER-A520/A530 Dealer Knowledge Book
Page 102 of 266 Specifications subject to change without notice: Revision date 10/07
Department Type - 2110
XX : Dept Code 01-99
ABCDEF : See Below
A: Item Validation: Compulsory/Not 1/0
B: Tare Table No. Assignment: 1-9/0
C: Scale Entry: Compulsory/Enable/Inhibit 2/1/0
D: SIF/SICS/Normal: 2/1/0
E: Bottle Return/Hash/Normal 2/1/0
F: Amount Entry Type Open&Preset/Preset/Open/Inhibit 3/2/1/0
MRS = 000001
