ER-A520/A530 Dealer Knowledge Book
Page 214 of 266 Specifications subject to change without notice: Revision date 10/07
Quick Steps - CAT
No. Description Comments/Procedures
Step–1 Connect the CAT CH–1 or CH–2 (Recommended CH-2)
Step–2
PGM Job#2690
2690 Æ [.] Æ [@] Æ 3 Æ @ Æ 0001 [SBTL] Æ [CA/AT] for CH–1) or
2690 Æ [.] Æ [@] Æ 3 Æ @ Æ 0002 [SBTL] Æ [CA/AT] for CH–2)
Note: Must match the physical connection
Step–3
Program Reset
• Place the SRV-Key counter-clockwise to 6 o’clock position (SRV’ position)
• Count 5 seconds
• Turn SRV-Key clockwise to 7o’clock position (SRV position)
• Verify”***PROGRAM RESET has printed on the journal-side tape.
Step-4 PGM Job#7110 7110 Æ[.] Æ[@]Æ(Telephone No.) Æ[CASH]
(Telephone No.for Dial Out))
Note: This information comes from Datacap.
Step-5
PGM Job #7111
7111 Æ[.] Æ[@] xxxxxxxx Æ[CASH]
(Password for Merchant Parameter)
Note: This information comes from Datacap.
Step-6
PGM Job#7112
7112 Æ[.] Æ[@]Æ ABC Æ[CASH]
A: Food Stamp mode Disable/Enable = 0/1
B: PIN Pad for CAT is preset No/Yes = 1/0
C: Key Type for PIN Pad Index/Dukpt/Static = 2/1/0
D: Dial Mode for Dialing Pulse/Tone = 1/0
Note: This information comes from Datacap. (MRS =0 000. Change to 0100).
Step-7 PGM Job #7113 7113 Æ[.] Æ[@]Æ030Æ[CASH] (Time Out #1) – ½ min.
Wait for 1
st
ACK reply.
Note: MRS Default = 030. Change to 010.
Step-8 PGM Job #7114 7114 Æ[.] Æ[@]Æ180Æ[CASH] (Time Out #2) – 3 min.
Max. Response Wait.
Note: MRS Default = 090. Change to 180.
Step-9 PGM Job#7115 7115 Æ[.] Æ[@]Æ3000Æ[CASH] (Time Out #3) – 5min.
Max. Dial Out Wait
Note: MRS Default = 099. Change to 3000.
Step-10 PGM Job#2330
Example of Media Key Settings:
2330 Æ[.] Æ[@] Æ 114, 116, 118, 120, 122, 124, 126, 128, or 130 Æ[@] 1100000010X
Æ[SBTL]Æ[CASH] - (CHG1-CHG9), X = # of CAT receipts
2330 Æ[.] Æ[@] Æ 132 or 136 Æ[@] 1120000010X Æ[SBTL]Æ[CASH] - (CHK1-CHK5), X = # of Check
receipts
Step-11 PGM Job#7117 7117 Æ[.] Æ[@] Æ[CASH] (To initialize the Data Tran SL Unit)
To Next Page
