FO-71TH/UX-61TH/GQ-56TH/FO-51TH
UX-41TH/GQ-31TH/UX-21TH/FO-11TH/GQ-11TH
Fig. 8
3 – 10
Parts list (Fig. 8)
PO roller guide and head frame unit
8
2
3
4
5
1
6
13
13
14
14
12
2
3
4
5
1
7
8
9
6
12
13
11
10
Control
PWB
Hook
11
9
7
8
10
14
7 PO roller ass’y1
(FO-71/UX-61/GQ-56 only)
8 PO roller guide 1
(FO-71/UX-61/GQ-56 only)
9 Screw (3×10) 1
10 Earth plate 1
11 Head earth cable 1
12 Head frame unit 1
13 Screw (3×8) 2
14 Panel lock lever spring 2
No. Part name Q’ty No. Part name Q’ty
1 Mechanism unit 1
2 Screw (3×6) 1
3 Connector 1
4 Screw (3×8) 1
(FO-71/UX-61/GQ-56 only)
5 PO roller guide unit 1
(FO-71/UX-61/GQ-56 only)
6 PO gear 1
(FO-71/UX-61/GQ-56 only)
