Sharp FP-R65CX - Preparation; Filter Installation

PREPARATION
To maintain the quality of the filters, they are installed in the main unit within plastic bags.
Be sure to remove the filters from the plastic bags before using the unit.
Remove the filters
Remove the Front Panel.
Remove the ActiveCarbonFilter(black) and True HEPA Filter (white)
from the plastic bags.
E-8
Be sure to remove the power plug from the wall outlet.
FILTER INSTALLATION
Pull out the Filter Frame and remove the Pre-Filter.
Push in the hooks, then pull
the Front Panel.
4
2
1
Remove the True HEPA Filter.
Preparing Active Carbon Filter.
3
Front Panel
Hook
Pre-Filter
Filter Frame
Active Carbon Filter
(At open)
Pre-Filter
True HEPA Filter
Filter Frame
Active Carbon Filter
True HEPA Filter
1
