LC-19D1E/S-BK/WH
5 – 17
65 FMIADDR14 O Adress data 14 (for flash ) FMIADDBE14
66 FMIADDR13 O Adress data 13 (for flash ) FMIADDBE13
69 FMIADDR12 O Adress data 12 (for flash ) FMIADDBE12
70 FMIADDR11 O Adress data 11 (for flash ) FMIADDBE11
71 FMIADDR10 O Adress data 10 (for flash ) FMIADDBE10
72 FMIADDR9 O Adress data 9 (for flash ) FMIADDBE9
73 FMIADDR8 O Adress data 8 (for flash ) FMIADDBE8
74 FMIADDR7 O Adress data 7 (for flash ) FMIADDBE7
75 FMIADDR6 O Adress data 6 (for flash ) FMIADDBE6
76 FMIADDR5 O Adress data 5 (for flash ) FMIADDBE5
77 FMIADDR4 O Adress data 4 (for flash ) FMIADDBE4
78 FMIADDR3 O Adress data 3 (for flash ) FMIADDBE3
79 FMIADDR2 O Adress data 2 (for flash ) FMIADDBE2
80 FMIADDR1 O Adress data 1 (for flash ) FMIADDBE1
81 FMIADDR0 O Adress data 0 (for flash ) FMIADDBE0
52 NOT_FMICSD O Chip select D TL
51 NOT_FMICSC/ADDR24 O Chip select C TL
50 NOT_FMICSB O Chip select B CIEN
49 NOT_FMICSA O Chip select A NFMICSA
88 NOT_FMIOE O Output enable NFMIOE
86 NOT_FMIBE1 O Byte enable 1 NOTBEI
87 NOT_FMIBE0 O Byte enable 0 TL
85 NOT_FMILBA O Flash device load burst address NFMILBA
83 FMIRDNOTWR O Read not write FMIRDNWR
82 FMIWAIT I Wait input (extend read/write cycle) FMI WAIT
53 FMIFLASHCLK O Peripheral clock TL
SDRAM interface for LMI (Local Management Interface)
201 LMIDATA15 I/O Bidirectional data 15 (for SDRAM ) LMIDBE15
199 LMIDATA14 I/O Bidirectional data 14 (for SDRAM ) LMIDBE14
198 LMIDATA13 I/O Bidirectional data 13 (for SDRAM ) LMIDBE13
197 LMIDATA12 I/O Bidirectional data 12 (for SDRAM ) LMIDBE12
194 LMIDATA11 I/O Bidirectional data 11 (for SDRAM ) LMIDBE11
192 LMIDATA10 I/O Bidirectional data 10 (for SDRAM ) LMIDBE10
191 LMIDATA9 I/O Bidirectional data 9 (for SDRAM ) LMIDBE9
190 LMIDATA8 I/O Bidirectional data 8 (for SDRAM ) LMIDBE8
180 LMIDATA7 I/O Bidirectional data 7 (for SDRAM ) LMIDBE7
178 LMIDATA6 I/O Bidirectional data 6 (for SDRAM ) LMIDBE6
175 LMIDATA5 I/O Bidirectional data 5 (for SDRAM ) LMIDBE5
174 LMIDATA4 I/O Bidirectional data 4 (for SDRAM ) LMIDBE4
171 LMIDATA3 I/O Bidirectional data 3 (for SDRAM ) LMIDBE3
169 LMIDATA2 I/O Bidirectional data 2 (for SDRAM ) LMIDBE2
168 LMIDATA1 I/O Bidirectional data 1 (for SDRAM ) LMIDBE1
167 LMIDATA0 I/O Bidirectional data 0 (for SDRAM ) LMIDBE0
206 LMIADDR12 O Adress data 12 (for SDRAM ) LMIABE12
209 LMIADDR11 O Adress data 11 (for SDRAM ) LMIABE11
157 LMIADDR10 O Adress data 10 (for SDRAM ) LMIABE10
210 LMIADDR9 O Adress data 9 (for SDRAM ) LMIABE9
211 LMIADDR8 O Adress data 8 (for SDRAM ) LMIABE8
213 LMIADDR7 O Adress data 7 (for SDRAM ) LMIABE7
214 LMIADDR6 O Adress data 6 (for SDRAM ) LMIABE6
215 LMIADDR5 O Adress data 5 (for SDRAM ) LMIABE5
216 LMIADDR4 O Adress data 4 (for SDRAM ) LMIABE4
150 LMIADDR3 O Adress data 3 (for SDRAM ) LMIABE3
152 LMIADDR2 O Adress data 2 (for SDRAM ) LMIABE2
153 LMIADDR1 O Adress data 1 (for SDRAM ) LMIABE1
154 LMIADDR0 O Adress data 0 (for SDRAM ) LMIABE0
159 LMIBA1 O Bank select 1 LMIBABE1
160 LMIBA0 O Bank select 0 LMIBABE0
182 LMIDQM0 O Data I/O mask lower LMIDQMBE0
186 LMIDQM1 O Data I/O mask upper LMIDQMBE1
181 LMIDQS0 O Data strobe lower (DDR). Not used when SDR connected to LMI LMIDQSBE0
188 LMIDQS1 O Data strobe upper (DDR). Not used when SDR connected to LMI LMIDQSBE1
162 NOT_LMICS O Chip select NLMICSBE
163 NOT_LMIRAS O Latch row address strobe NLMIRASBE
Pin No. Pin Name I/O Pin Function sheet name
To Next Page
