LC-32/37A33T
2 – 4
Preparation
Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
Attach the stand in the correct direction.
Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Attaching the stand
1
3
Ԙ
Insert the stand into the openings on the
bottom of the TV.
ԙ
Insert and tighten the 4 screws into the 4
holes on the rear of the TV.
Hex key
Screw
Soft
cushion
NOTE
To detach the stand, perform the steps in reverse order.
2
Hex
key
Screw
Attach the supporting post for the stand unit
onto the base as shown below.
Confirm the screws supplied with the TV.
Screws ( 4)
(usedinstep3)
Screws ( 5)
(usedinstep2)
To Next Page
