LC-32/37A33T

Service Manual

OUTLINE AND DIFFERENCES FROM BASE MODEL

OUTLINE

This model is based on the LC-32A33M and is changed some parts. This Service Manual covers the modifications alone. For the other points, refer to

the LC-32A33M (No. SY7B8LC32A33M) Service Manual.

DIFFERENCES FROM BASE MODEL

LIST OF CHANGED PARTS (LC-32A33T)

Ref. No. Description

LC-32A33M

(No. SY7B8LC32A33M)

LC-32A33T

(No. SY8T8LC37A33T)

Note

PRINTED WIRING BOARD ASSEMBLIES

R/C, LED Unit DUNTKE264FM03 ← —

KEY Unit DUNTKE266FM03 ← —

MAIN Unit DUNTKE508FM02 DUNTKE508FM15 Some internal parts changed

INVERTER/POWER Unit RUNTKA419WJQZ RUNTKA419WJN1 Change (Unit Replacement Item)

LCD PANEL

LCD Panel Module Unit R1LK315T3GW20W R1LK315T3GW30W Change

MAIN Unit

C8220 Capacitor RC-KZA620WJZZY — Delete

C8221 Capacitor RC-KZA620WJZZY — Delete

C8447 Capacitor VCKYCY1EB104KY — Delete

C8448 Capacitor VCCCCZ1HH680JY — Delete

C8449 Capacitor VCCCCZ1HH680JY — Delete

C8450 Capacitor VCCCCZ1HH101JY — Delete

C8451 Capacitor VCCCCZ1HH101JY — Delete

C8452 Capacitor VCAAPC1CJ226MY — Delete

C8453 Capacitor VCAAPC1CJ226MY — Delete

C8454 Capacitor VCCCCZ1HH101JY — Delete

C8455 Capacitor RC-KZA213WJZZY — Delete

C8456 Capacitor RC-KZA620WJZZY — Delete

C8457 Capacitor VCKYCY1EB104KY — Delete

C8460 Capacitor RC-KZA211WJZZY — Delete

IC801 IC RH-IXB886WJZZQ RH-IXB887WJZZQ Change

IC8403 IC VHITB6815FG-1Y — Delete

IC8404 IC RH-IXB420WJZZY — Delete

Q8412 Transistor VSTPCP8505+-1Y — Delete

Q8413 Transistor VSTPCP8602+-1Y — Delete

Q8414 Transistor VSTPCP8505+-1Y — Delete

R1340 Resistor VRS-TW2ED000JY — Delete

R1341 Resistor VRS-TW2ED000JY — Delete

R1342 Resistor VRS-TW2ED000JY — Delete

R8235 Resistor VRS-CZ1JF183FY — Delete

R8236 Resistor VRS-CZ1JF912FY — Delete

R8238 Resistor VRS-CZ1JF913FY — Delete

R8239 Resistor VRS-CZ1JF183FY — Delete

R8240 Resistor VRS-CZ1JF163FY — Delete

R8241 Resistor VRS-CZ1JF913FY — Delete

R8463 Resistor VRS-CZ1JF332FY — Delete

R8464 Resistor VRS-CZ1JF332FY — Delete

R8465 Resistor — VRK-SB1FF000JY Add

R8467 Resistor VRS-CZ1JF330JY — Delete

R8469 Resistor VRS-CZ1JF1R0JY — Delete

R8470 Resistor VRS-CZ1JF330JY — Delete

R8471 Resistor VRS-CZ1JF102FY — Delete

R8472 Resistor VRS-CZ1JF102FY — Delete

R8473 Resistor VRS-CZ1JF330JY — Delete

R8474 Resistor — VRK-SB1FF000JY Add

R8476 Resistor VRS-CZ1JF000JY — Delete
