PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32/37A33T
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
No. SY8T8LC37A33T
LC-32A33T
LC-37A33T
MODELS
LCD COLOUR TELEVISION
PartsGuide
[1] PRINTED WIRING BOARD ASSEMBLIES
[2] LCD PANEL
[3] DUNTKE508FM15 (LC-32A33T)
DUNTKE508FM16 (LC-37A33T)
(MAIN Unit)
[4] CABINET AND MECHANICAL PARTS
(LC-32A33T)
[5] LCD PANEL UNIT (LC-32A33T)
[6] CABINET AND MECHANICAL PARTS
(LC-37A33T)
[7] LCD PANEL UNIT (LC-37A33T)
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS (NOT REPLACEMENT ITEM)
[10] SERVICE JIG (USE FOR SERVICING)
