LC-32/37A33T
4 – 6
[2] REMOVING OF MAJOR PARTS (LC-37A33T)
1. REMOVING OF STAND ASS'Y AND REAR CABINET
1. Remove the 4 screws [1] and detach the Stand Ass'y.
2. Detach the Bass Cover [2].
3. Remove the 2 screws [3], 2 screws [4], 4 shafts [5], 4 screws [6], 6 screws [7] and detach the Rear Cabinet.
Stand Ass'y
Rear Cabinet
1
4
5
2
Bass Cover
3
6
7
7
