Sharp LC-32A33T User Manual

LC-32/37A33T
4 – 5
5. REMOVING OF CENTER ANGLE AND LCD ANGLE-A/B
1. Remove the 2 screws [1], 2 screws [2], 8 screws [3] and detach the Center Angle.
2. Remove the 2 screws [4], 4 screws [5] and detach the LCD Angle-A/B.
3. Detach the LCD Panel Module.
4
3
2
2
4
5
5
5
5
3
1
Center Angle
LCD Angle-A
LCD Angle-B
LCD Angle-A
LCD Panel Module
LCD Angle-B
Center Angle
1
