Sharp LC-32A33T User Manual

LC-32/37A33T
4 – 7
2. REMOVING OF SPEAKERS, BOTTOM COVER AND STAND ANGLE
1. Remove the 1 screw [1] and detach the Bottom Cover.
2. Remove the 4 screws [2] and detach the Stand Angle.
3. Disconnect SP connector and detach the Speaker-L and Speaker-R [3].
4. Detach the Speaker Sheet [4].
Speaker-R
Speaker Sheet Speaker Sheet
Speaker-L
3
4 4
3
1
2
2
Bottom Cover
Stand Angle
䬌䎶䎳䬍
3
