LC-32/37A33T
ii
LIST OF CHANGED PARTS (LC-37A33T)
R8479 Resistor — VRS-CZ1JF000JY Add
R8480 Resistor VRS-CZ1JF000JY — Delete
R8482 Resistor VRS-CZ1JF1R0JY — Delete
R8483 Resistor VRS-CZ1JF1R0JY — Delete
R8485 Resistor — VRS-CZ1JF000JY Add
R8486 Resistor VRS-CZ1JF000JY — Delete
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS, ACCESSORIES AND SERVICE JIGS
Please refer to a Parts list
Ref. No. Description
LC-32A33M
(No. SY7B8LC32A33M)
LC-37A33T
(No. SY8T8LC37A33T)
Note
PRINTED WIRING BOARD ASSEMBLIES
R/C, LED Unit DUNTKE264FM03 ← —
KEY Unit DUNTKE266FM03 ← —
MAIN Unit DUNTKE508FM02 DUNTKE508FM16 Some internal parts changed
INVERTER/POWER Unit RUNTKA419WJQZ — Delete
POWER Unit — RDENCA288WJQZ Add (Unit Replacement Item)
INVERTER Unit — RUNTKA418WJN1 Add (Unit Replacement Item)
LCD PANEL
LCD Panel Module Unit R1LK315T3GW20W R1LK370T3GW20W Change
MAIN Unit
IC801 IC RH-IXB886WJZZQ RH-IXB887WJZZQ Change
R1340 Resistor VRS-TW2ED000JY — Delete
R1341 Resistor VRS-TW2ED000JY — Delete
R1342 Resistor VRS-TW2ED000JY — Delete
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS, ACCESSORIES AND SERVICE JIGS
Please refer to a Parts list
Ref. No. Description
LC-32A33M
(No. SY7B8LC32A33M)
LC-32A33T
(No. SY8T8LC37A33T)
Note
To Next Page
