LC-32LE240M/340M(1stEdition)
3 – 4
4. Removing of the Chassis Ass’y and LCD Panel Unit
1. Remove the 5 screws and detach the Chassis Ass’y .
2. Detach the LCD Panel Unit .
2Chassis Ass'y
3LCD Panel Unit
CAB-A Ass'y
1
