LC-32LE240M/340M(1stEdition)
4 – 2
6) Let the process running & entering verification.
7) Software is successfully installed when the following appears at the end of the process.
8) Plug off the LCD TV and plug ON again as usual.
9) LCD TV is running with the latest software.
4. EDID DATA INPUT
4.1. HDMI EDID
4.2. ANALOG PC EDID
NOTE: *1 HDMI EDID file name : edid_32LE340_HDMI1_111019.bin
NOTE: *2 PC EDID file name : 32LE340 PC EDID111019.bin
Main Software Package
Main Software File name : XXX is Software version
If any changes of software, will be informed by MARUHEN.
Adjustment item Adjustment conditions Adjustment procedure
1 EDID Input
(HDMI)
Inspection mode
Confirrm the file name/ver-
sion.
1) EDID data is input to IC1501 (HDMI INPUT1). *1
2) EDID data is input before HDMI operation checking.(Without EDID data, HDMI will
not function correctry)
Adjustment item Adjustment conditions Adjustment procedure
1 EDID Input
(ANALOG PC)
Inspection mode
Confirrm the file name/ver-
sion.
1) EDID data is input to IC508 (PC INPUT) at checker line. *2
2) EDID data is input before Analog PC operation checking.
Model Software Package
32LE340M ORCD_MM_Asia_Pack03_vXXX.bin
32LE240M ORCD_MM_Asia_Pack04_vXXX.bin
Verifying
Verified
Please re-boot the system
Update Finished
To Next Page
