LC-32LE240M/340M(1stEdition)
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKF998FMG4 N V MAIN Unit (LC-32LE340M)
N DKEYMF998FMG5 N V MAIN Unit (LC-32LE240M)
N RUNTKA929WJQZ N V POWER Unit
N RUNTKA927WJZZ N V LED PWB-A
N RUNTKA928WJZZ N V LED PWB-B
[2] LCD PANEL
N R1LK315T3HB00W N V LCD Panel Unit
[3] DKEYMF998FMG4/5 (MAIN Unit)
C102 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C103 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C501 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C502 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C503 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C504 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C508 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C509 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C514 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C515 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C517 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C518 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C526 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C527 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C530 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C531 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C532 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C533 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C543 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C544 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C548 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C553 VCCCCZ1HH102JY AA J Capacitor 1000p 50V Ceramic
C560 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C561 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C565 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C566 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C581 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1103 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1105 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1106 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1107 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1108 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1110 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1113 VCKYCZ1EB103KY AA J
Capacitor 0.01 25V Ceramic
C1114 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1115 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1116 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1117 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1118 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1120 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1121 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1122 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1123 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1501 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1502 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1701 RC-KZA838WJQZY AB J Capacitor 10 25V Ceramic
C1702 RC-KZA838WJQZY AB J Capacitor 10 25V Ceramic
C1704 RC-KZA838WJQZY AB J Capacitor 10 25V Ceramic
C1705 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1706 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1707 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1708 RC-KZA621WJQZY AA J Capacitor 1 25V Ceramic
C1709 RC-KZA621WJQZY AA J Capacitor 1 25V Ceramic
C1710 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
C1711 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
C1712 RC-KZA621WJQZY AA J Capacitor 1 25V Ceramic
C1713 RC-KZA621WJQZY AA J Capacitor 1 25V Ceramic
C1714 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
C1715 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
C1716 RC-KZA709WJQZY AA J Capacitor 0.22 25V Ceramic
C1717 RC-KZA709WJQZY AA J Capacitor 0.22 25V Ceramic
C1718 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1731 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C1732 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C1901 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1902 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1903 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1904
VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1905 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1907 VCCCCZ1HH821JY AA J Capacitor 820p 50V Ceramic
C1908 VCCCCZ1HH821JY AA J Capacitor 820p 50V Ceramic
C1909 RC-KZA837WJQZY AB J Capacitor 10 10V Ceramic
C1910 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1911 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1912 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
