Preparation
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector,
plug it into the antenna terminal at the rear of the TV set.
fl,A 75-ohm system isgenerallya round cablewith F-type connector ;--F-type connector
that can easilybe attachedto a terminal without tools (Commercially 75-ohm coaxialcable (round)
available).
2.A 300-ohm system is a flat "twin-lead"cable that can be attached
to a 75-ohm terminalthrough a 300/75-ohm adapter (Commercially
available), 300-ohm twin-lead cable (flat)
F-type connector
When connecting the RF cable to the TV set, do not tighten F-type
connector with tools.
If tools are used, it may cause damage to your TV set. (The breaking 75-ohm coaxial cable
in!erna! circui! _e!c:) -_,
*Connecting Antenna
_, Connect the antenna cable to the TV using one of the methods in the illustration as shown ((_), (_), (_ or (_).
Home Antenna
terminal (75 ohm)
(_) Cable without a CATV CableTVlead,_ [_ c_-? --
converter Coaxial cable [_ _[
_7 (commercially available)
(_) VHF/UHF antenna HomeAnt ......
terminal (75 ohm)
5ohmcoaxialcable(round) _ _-__-] m
Coaxial cable
@ Combination VHF/ _-_ /............_a,yava,able/
UHF antenna _oh .......ialcable/roun./ T "_']
or
300/75 ohm adapter
(commercially avadable)
_ 300 ohm twin lead cable (flat) [ =J
@ Separate VHF/UHF VHF UHF
ANTENNA ANTENNA 300 ohrn
antenna
300 ohm twin lead cable | Combiner
' 1 (commercially available)
I°r 7sohmcoa×ia_cable _ J To TV antenna
terminal
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
1 Open the battery cover. 2 Insert two "AAA" size batteries 3 Close the battery cover.
(supplied with the product).
Place the batteries with their terminals
corresponding to the (+) and (-)
indications in the battery compartment.
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
Do not mix batteries of different types. Different types of batteries have different characteristics.
Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage
in old batteries.
Remove batteries as soon as they are worn out. Chemicals that leak from batteries come in contact with skin can cause a
rash. Ifyou find any chemical leakage, wipe thoroughly with a cloth.
The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
If you will not be using the remote control unit for an extended period of time, remove batteries from it.
(!_-8
