Sharp LC-37D44E Service Manual

LC-37D44E/S/RU-BK/GY
18
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R8453 VRS-CZ1JF183FY AA J Resistor 18k 1/16W Metal Oxide
R8454 VRS-CZ1JF334FY AA J Resistor 330k 1/16W Metal Oxide
R8455 VRS-CZ1JF153FY AA J Resistor 15k 1/16W Metal Oxide
R8456 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R8457 VRS-TQ2BD511JY AA J Resistor 510 1/8W Metal Oxide
R8458 VRS-TQ2BD511JY AA J Resistor 510 1/8W Metal Oxide
R8459 VRS-CZ1JF513FY AA J Resistor 51k 1/16W Metal Oxide
R8460 VRS-CZ1JF203FY AA J Resistor 20k 1/16W Metal Oxide
R8461 VRS-TQ2BD511JY AA J Resistor 510 1/8W Metal Oxide
R8491 VRS-CZ1JF113FY AA J Resistor 11k 1/16W Metal Oxide
R8492 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R8493 VRS-CZ1JF682FY AA J Resistor 6.8k 1/16W Metal Oxide
R8494 VRS-CZ1JF204FY AA J Resistor 200k 1/16W Metal Oxide
R8495 VRS-CZ1JF183FY AA J Resistor 18k 1/16W Metal Oxide
R8496 VRS-CZ1JF683FY AA J Resistor 68k 1/16W Metal Oxide
R8497 VRS-CZ1JF393FY AA J Resistor 39k 1/16W Metal Oxide
R8499 VRS-TV1JD000JY AA J Resistor 0 1/10W Metal Oxide
R8500 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R8502 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R8504 VRS-TW2HF3R3JY AA J Resistor 3.3 1/2W Metal Oxide
R8505 VRS-TV1JD3R3JY AA J Resistor 3.3 1/10W Metal Oxide
R8506 VRS-TV1JD101JY AA J Resistor 100 1/10W Metal Oxide
R8507 VRS-CZ1JF105JY AA J Resistor 1M 1/16W Metal Oxide
R8508 VRS-CZ1JF474JY AA J Resistor 470k 1/16W Metal Oxide
SC1101 QSOCZA161WJZZ AG J Socket 21Pin (INPUT 2)
SC1102 QSOCZA161WJZZ AG J Socket 21Pin (INPUT 2)
SC1201 QSOCNA770WJZZ AG N J Socket 17Pin (PC-IN(BLACK))
SC1501 QSOCNA769WJZZ AG N J Socket 11Pin (RS232C)
SC1901 QSOCZA171WJZZY AF J Socket 23Pin
SC1921 QSOCZA171WJZZY AF J Socket 23Pin
SC4401 QSOCJA002WJZZQ AQ N J Socket 68Pin
SC8201 QCNCW2367WJZZY AG J Socket 80Pin
SC8202 QCNCW2367WJZZY AG J Socket 80Pin
TH2301 VHHM1103J03-1Y AC J
Thermistor
!
TU201 RTUDAA019WJQZ BC P Tuner
X201 RCRSCA039WJZZY AG J Crystal
X1951 RCRSCA146WJZZY AE J Crystal 28.322MHz
X2301 RCRMCA011WJZZY AD J Crystal
X3051 RCRSC0012CEZZY AH J Crystal 20.25MHz
X4001 RCRSCA039WJZZY AG J Crystal
N NSFTZA243WJFN AB J Shaft, x4 (D-SUB)
N PRDARA577WJFW AF N J Heat Sink (VCT-Pro)
N PSPAZB311WJKZ AE J Spacer (VCT-Pro)
N XBPSN20P10JS0 AD J Screw, x2 (Card Slot)
[4] DUNTKE457FM03 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor 2.2 16V Ceramic
C107 VCEASY1CN107MY AC J Capacitor 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode UDZSNPTE-1712B
D103 RH-PX0421CEZZY AD J Photo Diode CL-165HR/YG-D-T
P101 QPLGNA339WJZZY AD J Plug 5pin (RA)
R101 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R108 VRS-CY1JF151JY AA J Resistor 0 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Control
SLD101 PSLDPA076WJFW AD J Shield Case
[5] DUNTKE266FM01 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug 5Pin(KM)
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch CH UP
S152 QSW-K0003AJZZ+ AB J Switch CH DOWN
S153 QSW-K0003AJZZ+ AB J Switch CH INPUT
S154 QSW-K0003AJZZ+ AB J Switch VOL UP
S155 QSW-K0003AJZZ+ AB J Switch VOL DOWN
S156 QSW-K0003AJZZ+ AB J Switch CH MENU
S157 QSW-K0003AJZZ+ AB J Switch CH POWER
[3] DUNTKE449FM03 (MAIN Unit)
