LC-37D44E/S/RU-BK/GY
1 – 1
LC37D44E-BK
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item
37" LCD COLOUR TV, Model: LC-37D44E, LC-37D44S, LC-37D44RU
LCD panel
37" Advanced Super View & BLACK TFT LCD
Resolution
1,049,088 pixels (1,366 x 768)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
TV-Standard Analogue CCIR (B/G, I, D/K, L,L’)
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF E2–E69ch, F2–F10ch, I21–I69ch, IR A–IR Jch, (Digital: E5–E69ch)
CATV Hyper-band, S1–S41ch
TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Brightness 450 cd/m
2
(in Dynamic Mode)
Viewing angles H : 176° V : 176°
Audio amplifier
10W x 2
Speaker
(145 mm x 35 mm) x 2
Terminals Antenna
UHF/VHF 75
Ω Din type (Analogue & Digital)
RS-232C 9 pin mini D-sub
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 SCART (AV input/output, Y/C input, RGB input, AV Link)
EXT 3 S-VIDEO (Y/C input), RCA pin (AV input)
EXT 4 Ø 3.5 mm jack (Audio input), 15 pin mini D-sub (PC)
EXT 5 Audio in, Component in
EXT 6 HDMI, Ø 3.5 mm jack (Audio input)
EXT 7 HDMI
C. I. (Common Interface) EN50221, R206001
OUTPUT RCA pin (Audio)
Headphones Ø 3.5 mm jack (Audio output)
Power Requirement AC 220–240V, 50 Hz
Power Consumption 146 W (0.9 W Standby) (Method IEC60107)
Weight 14.5 kg (Display only), 17.0 kg (Display with stand)
Operating temperature
0°C to + 40°C
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
NOTE
• Refer to inside back cover for dimensional drawings.
Optional accessory
The listed optional accessories are available for the
LCD colour TV. Please purchase them at your nearest
shop.
• Additional optional accessories may be available in near
future. When purchasing, please read the newest catalogue
for compatibility and check the availability.
Part name Part number
Wall mount bracket
(LC-37D44E, LC-37D44S, LC-37D44RU)
AN-37AG5
