<During external connection> No picture on the monitor (3)
SCART2:
No picture from EXT1 appears on EXT2-connected monitor.
NOTE: Normally, if the screen during display is sent to EXT2, no picture is sent to EXT2.
Checklist:
1) Is the Signal Type (item) in MENU-Option-Input Select equal to Signal Type of an external device? ... Set it to “CVBS”, “Y/C” or “RGB”.
2) The picture is sent to the monitor in a CVBS signal if the source during display is TV, CVBS or Y/C of EXT1-3.
3) When the monitor picture is not sent and is not displayed on the monitor, refer to “No picture” for each terminal.
When sent by component, etc., that signal is not sent to the monitor.
4) The video output from EXT1 is not the monitor output (output of the picture now watching).
The picture of the last selected TV channel is always sent to EXT1. (Specification)
Is CVBS signal output into pin(19) of SC1101(SCART2)
from pin(2) of IC1101(SW)?
YES Check the setting of an external input device that connects of SC1101.
NO
Is CVBS signal output into pin(194) of
IC3001(MAIN_MICON) from pin(6) of IC1101?
YES Check the line between IC1101 and SC1101.
NO
Is video signal (VIN2) from EXT1 sent to pin (190) of
IC3001 (MAIN_MICON)?
YES Check power supply of IC3001 and peripheral circuits.
NO
Is CVBS signal sent to pin (20) of SCART1(SC1102)? YES Check the line between SC1102 and IC3001.
(IC1502, SCART12_LINE, etc.)
NO
Check the setting of an external input device that con-
nects of SC1102.
To Next Page
