Sharp LC-37D44E Service Manual

LC-37D44E/S/RU-BK/GY
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE449FM03 CP N R MAIN Unit
N DUNTKE457FM03 AQ N R R/C, LED Unit
N DUNTKE266FM01 AR N R KEY Unit
N DUNTKE491FM01 AY N R MINI-AV Unit
N RDENCA267WJQZ BM N P POWER Unit
N RUNTKA497WJQZ BH N P INVERTER Unit
[2] LCD PANEL
N R1LK370T3GW2AY EC N J 37" LCD Panel Module
[3] DUNTKE449FM03 (MAIN Unit)
C201 VCEASX1AN336MY AC J Capacitor 33 10V Electrolytic
C207 VCEASX1CN477MY AE J Capacitor 470 16V Electrolytic
C209 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C210 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C213 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C214 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C215 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C216 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C217 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C218 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C219 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C220 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C221 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C222 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C223 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C224 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C225 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C226 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C227 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C228 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C229 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C230 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C231 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C232 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C233 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C234 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C235 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C236 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C237 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C238 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C239 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C240 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C241 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C242 VCKYCZ1EF104ZY AA J
Capacitor 0.1 25V Ceramic
C243 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C244 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C245 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C246 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C247 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C248 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C249 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C250 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C251 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C252 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C253 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C254 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C255 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C256 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C269 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C271 VCEASX1CN107MY AC J Capacitor 100 16V Electrolytic
C1005 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1006 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1007 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1008 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C1009 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C1010 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C1011 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C1012 VCEASY1CN476MY AC J Capacitor 47 16V Electrolytic
C1013 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1014 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1015 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C1016 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C1017 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1018 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C1019 VCEASX1CN226MY AC J Capacitor 22 16V Electrolytic
C1031 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1032 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C1033
VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C1034 VCEASX1CN106MY AC J Capacitor 10 16V Electrolytic
C1035 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C1101 RC-KZA176WJZZY AC J Capacitor 10 10V Ceramic
C1102 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1103 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C1104 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
