Sharp LC-37D44E Service Manual

LC-37D44E/S/RU-BK/GY
12
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
P2302 QPLGNA329WJZZY AD J Plug 9Pin(LB)
P2701 QPLGNA160WJZZY AD J Plug 4Pin(SP)
P3071 QPLGNA324WJZZY AC J Plug 4Pin(KM)
P3081 QPLGN0567FJZZY AD J Plug 5Pin
P4001 QPLGN0463TAZZY AC J Plug, 4Pin(RS)
P4401 QCNCMA313WJSA AK J Plug
Q203 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q204 RH-TXA026WJZZY AD J Transistor PBLS2001D,115
Q1001 VSiMH23T110-1Y AC J Transistor IMH23T110
Q1031 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q1101 VSiMH23T110-1Y AC J Transistor IMH23T110
Q1102 VSiMH23T110-1Y AC J Transistor IMH23T110
Q1105 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1106 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1107 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1108 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1301 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1302 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q1303 VSiMH23T110-1Y AC J Transistor IMH23T110
Q1501 VSSM3K7002F-1Y AC J Transistor SSM3K7002F(5LTST,F)
Q1801 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1802 VSDTA124EKA-1Y AB J Transistor DTA124EKAT146
Q1901 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1902 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1903 VSSSM3K15F+-1Y AB N J Transistor SSM3K15F
Q1904 VSSSM3K15F+-1Y AB N J Transistor SSM3K15F
Q1905 VSRN4904///-1Y AB J Transistor RN4904
Q1906 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1921 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1922 VSRDTC144EE-1Y AA J Transistor PDTC144EE,115
Q1923 VSSSM3K15F+-1Y AB N J Transistor SSM3K15F
Q1924 VSSSM3K15F+-1Y AB N J Transistor SSM3K15F
Q1925 VSRN4904///-1Y AB J Transistor RN4904
Q2701 VSDTC614TK+-1Y AB J
Transistor DTC614TKT146
Q3051 VSSM3K7002F-1Y AC J Transistor SSM3K7002F(5LTST,F)
Q3052 VSSM3K7002F-1Y AC J Transistor SSM3K7002F(5LTST,F)
Q4001 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q4002 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q4403 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q8401 VSEMZ1+++++-1Y AC J Transistor EMZ1T2R
Q8402 VSDTC114EE/-1Y AB J Transistor DTC114EETL
Q8403 VSTPCP8602+-1Y AD J Transistor VSTPCP8602+-1Y
Q8404 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q8405 VSTPCP8505+-1Y AD J Transistor VSTPCP8505+-1Y
Q8408 VS2SD1767++-1Y AD J Transistor 2SD1767T100
Q8410 VSRK7002A++-1Y AB J Transistor RK7002AT116
Q8450 VSRSS050P03-1Y AG J Transistor RSS050P03TB
R206 VRK-SA1JF220JY AA J Resistor 22 1/16W Metal Composition
R211 VRS-CZ1JF392JY AA J Resistor 3.9k 1/16W Metal Oxide
R212 VRS-CZ1JF151JY AA J Resistor 150 1/16W Metal Oxide
R213 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R214 VRS-CZ1JF331JY AA J Resistor 330 1/16W Metal Oxide
R218 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R222 VRK-SA1JF472JY AA J Resistor 4.7k 1/16W Metal Composition
R223 VRK-SA1JF220JY AA J Resistor 22 1/16W Metal Composition
R224 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R225 VRK-SA1JF103JY AB J Resistor 10k 1/16W Metal Composition
R226 VRS-CZ1JF561JY AA J Resistor 560 1/16W Metal Oxide
R227 VRS-CZ1JF561JY AA J Resistor 560 1/16W Metal Oxide
R228 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R229 VRS-CZ1JF181JY AA J Resistor 180 1/16W Metal Oxide
R230 VRS-CG1JF103JY AB J Resistor 10k 1/16W Metal Oxide
R233 VRK-SA1JF220JY AA J Resistor 22 1/16W Metal Composition
R234 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R236 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R237 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R238 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R239
VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R240 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R1006 VRS-CZ1JF682JY AA J Resistor 6.8k 1/16W Metal Oxide
R1010 VRS-CZ1JF392JY AA J Resistor 3.9k 1/16W Metal Oxide
R1011 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R1012 VRS-TQ2EF560JY AA J Resistor 56 1/4W Metal Oxide
R1013 VRS-TQ2EF560JY AA J Resistor 56 1/4W Metal Oxide
R1014 VRK-SA1JF182JY AC J Resistor 1.8k 1/16W Metal Composition
R1015 VRS-TW2HF820JY AB J Resistor 82 1/2W Metal Oxide
R1016 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1017 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R1018 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1019 VRS-CZ1JF122JY AA J Resistor 1.2k 1/16W Metal Oxide
R1020 VRS-CZ1JF122JY AA J Resistor 1.2k 1/16W Metal Oxide
R1021 VRK-SA1JF103JY AB J Resistor 10k 1/16W Metal Composition
R1022 VRK-SA1JF103JY AB J Resistor 10k 1/16W Metal Composition
R1023 VRK-SA1JF103JY AB J Resistor 10k 1/16W Metal Composition
R1031 VRS-CZ1JF331FY AA J Resistor 330 1/16W Metal Oxide
[3] DUNTKE449FM03 (MAIN Unit)
