LC-42SB45U
4
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Specification
Item Model:LC-42SB45U
LCD panel a-si TFT LCD 42" Class
Resolution 2,073,600 pixels(1,920x1,080)
TV Function
TV-standard(CCIR) American TV standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch,UHF 14-69ch
CATV 1-135ch(non-scrambled channel only)
Digital terrestrial
Broadcast(8VSB)
2-69ch
Digital cable
(64/256QAM)
1-135ch(non-scrambled channel only)
Audio multiplex BTSC System
Backlight 60,000 hours(at Backlight standard position)
Audio out 10Wx2
Terminals
Rear
INPUT 1 COMPONENT in,AUDIO in
INPUT 2 COMPONENT in,AUDIO in
INPUT 4 HDMI in with HDCP
INPUT 5 HDMI in with HDCP,Audio on(3.5mm jack)
INPUT 7 15-pin mini D-sub femal connector,Audio in(3.5mmjack)
ANT/CABLE 75 Unbalance,F Type x1 for Analog(VHF/UHF/CATV) and (AIR/CABLE)
DIGITAL AUDIO OUTPUT Digital audio output x1(PCM/DOLBY Digital)
Side
INPUT 3 AV in,S-VIDEO in
INPUT 6 HDMI in with HDCP
SERVICE Software update
OSD language English/French/Spanish
Power requirement
AC 120V,60Hz(For North America)
AC 110~240V,50-60Hz(For Others)
Power Consumption 220W(0.7W Standby with AC 120V)
Weight
TV+stand 48.72 lbs/22.1 kg
TV only 43.8 lbs/19.87 kg
Dimension
(W xH xD)
TV+stand 39.75x27.75x10.75 inch
TV only 39.75x27.62x3.88 inch
Operating temerature +32°F to +104°F(0°C to +40°C)
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations
from these values in individual units.
Optional accessory
The listed optional accessories are available for the LCD
colour TVs. Please purchase them at your nearest shop,
• Additional optional accessories may be available in the
near future. When purchasing, please read the newest
catalogue for compatibility and check the availability.
No. Part name Part number
1 Wall mount bracket AN-52AG4
