Sharp LC-45GD5U User Manual

26
LC-45GD5U
Page Line Item Description Remarks (adjustment detail, etc.)
1 [INFO]
1 MAIN Version Main software version
2
3Monitor Version Monitor software version
4 Vmouse Version Video mouse version
5 DVS Version DVS version
6 EQ DATA CHECKSUM Audio data checksum
7 TEMPERATURE CPU temperature
8 FAN STATUS FAN status ROTATE: rotating, STOP: stopped
9 STANDBY CAUSE Standby cause
2 [INIT]
1 INDUSTRY INIT Initialization to factory settings
2 HOTELMODE Hotel mode
3 Center Acutime
Accumulated main operation time
4 RESET Reset
5 BacklightAcutime
Accumulated monitor operation time
6 RESET Reset
7 VIC XPOS X-coordinate setting for VIC READ
8 VIC YPOS Y-coordinate setting for VIC READ
9 VIC COLOR Collected color data setting for VIC READ
10 VIC SIGNAL TYPE Signal type setting for VIC READ
11 VIC READ Picture level acquisition function Level appears in green on the upper right.
12 LAMP ERROR Number of termination due to lamp error
13 LAMP ERROR RESET Reset LAMP ERROR
3 [N358MAIN]
1 N358 ALL ADJ CVBS and TUNER signal level adjustment
2N358 MAIN ADJ CVBS signal level adjustment
3 TUNER DAC ADJ TUNER signal level adjustment
4 N358 MAIN CONTRAST CVBS and TUNER contrast adjustment values
5 N358 MAIN Cb GAIN CVBS and TUNER Cb gain adjustment values
6 N358 MAIN Cr GAIN CVBS and TUNER Cr gain adjustment values
7 TUNER A DAC TUNER adjustment value
4 [TUNER TEST]
1 TUNER VCHIP TEST(69ch) Tuning test and VCHIP test (69 ch)
2 TUNER VCHIP TEST(7ch) Tuning test and VCHIP test (7 ch)
3 TUNER VCHIP TEST(10ch) Tuning test and VCHIP test (10 ch)
4 TUNER VCHIP TEST(15ch) Tuning test and VCHIP test (15 ch)
5 MONIDATA READ[TEMP/OPC] Monitor temperature and OPC value indication Temperature and OPC value appear in green on the upper right.
5 [COMP15KMAIN]
1 COMP15K ALL ADJ Component 15K picture level adjustment
2 COMP15K MAIN ADJ Component 15K picture level adjustment (main) For models incompatible with picture-in-picture, same as COMP15K ALL ADJ
3 COMP15K MAIN CONTRAST Contrast adjustment value
4 COMP15K Cb GAIN Cb GAIN adjustment value
5 COMP15K Cr GAIN Cr GAIN adjustment value
6 COMP15K Y OFFSET Y OFFSET adjustment value
7 COMP15K Cb OFFSET Cb OFFSET adjustment value
8 COMP15K Cr OFFSET Cr OFFSET adjustment value
6 [HDTV]
1 HDTV ADJ Component Hi-Vision picture level adjustment
2 CONTRAST Contrast adjustment value
3 Cb GAIN Cb GAIN adjustment value
4 Cr GAIN Cr GAIN adjustment value
5 HDTV Y OFFSET Y OFFSET adjustment value
6 HDTV Cb OFFSET Cb OFFSET adjustment value
7 HDTV Cr OFFSET Cr OFFSET adjustment value
7 [HDMI]
1 HDMI ADJ HDMI picture level adjustment
2 CONTRAST Contrast adjustment value
3 Cb GAIN Cb GAIN adjustment value
4 Cr GAIN Cr GAIN adjustment value
5 HDMI Y OFFSET Y OFFSET adjustment value
6 HDMI Cb OFFSET Cb OFFSET adjustment value
7 HDMI Cr OFFSET Cr OFFSET adjustment value
5. List of adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
