27
LC-45GD5U
8 [DVI ANALOG]
1 DVI ANALOG ADJ DVI ANALOG adjustment
2R CUTOFF
R CUTOFF adjustment value
3G CUTOFF G CUTOFF adjustment value
4B CUTOFF B CUTOFF adjustment value
5R DRIVE R DRIVE adjustment value
6G DRIVE G DRIVE adjustment value
7B DRIVE B DRIVE adjustment value
9 [DVI DIGITAL]
1 DVI DIGITAL ADJ(DVI)
DVI DIGITAL picture level adjustment (input: DVI)
2 DVI DIGITAL ADJ(HDMI) DVI DIGITAL picture level adjustment (input: HDMI)
3R CUTOFF R CUTOFF adjustment value
4G CUTOFF G CUTOFF adjustment value
5B CUTOFF B CUTOFF adjustment value
6R DRIVE R DRIVE adjustment value
7G DRIVE G DRIVE adjustment value
8B DRIVE B DRIVE adjustment value
10 [M GAMMA]
1 MONITOR R GAMMA LO WB adjustment Low gradation R adjustment value Parameter for two-point adjustment
2 MONITOR G GAMMA LO WB adjustment Low gradation G adjustment value
3 MONITOR B GAMMA LO WB adjustment Low gradation B adjustment value
4 MONITOR R GAMMA HI WB adjustment High gradation R adjustment value
5 MONITOR G GAMMA HI WB adjustment High gradation G adjustment value
6MONITOR B GAMMA HI WB adjustment High gradation B adjustment value
7 GAMMA WRITE WB adjustment data writing
8 GAMMA RESET WB adjustment data reading
11 [M GAMMA6 R]
1 MONITOR R GAMMA 1 WB adjustment Point 1, R adjustment value Parameter for six-point adjustment
2 MONITOR R GAMMA 2 WB adjustment Point 2, R adjustment value
3 MONITOR R GAMMA 3 WB adjustment Point 3, R adjustment value
4 MONITOR R GAMMA 4 WB adjustment Point 4, R adjustment value
5 MONITOR R GAMMA 5 WB adjustment Point 5, R adjustment value
6 MONITOR R GAMMA 6 WB adjustment Point 6, R adjustment value
7 GAMMA WRITE WB adjustment data writing
8 GAMMA RESET WB adjustment data reading
12 [M GAMMA6 G]
1 MONITOR G GAMMA 1 WB adjustment Point 1, G adjustment value Parameter for six-point adjustment
2 MONITOR G GAMMA 2 WB adjustment Point 2, G adjustment value
3 MONITOR G GAMMA 3 WB adjustment Point 3, G adjustment value
4 MONITOR G GAMMA 4 WB adjustment Point 4, G adjustment value
5 MONITOR G GAMMA 5 WB adjustment Point 5, G adjustment value
6 MONITOR G GAMMA 6 WB adjustment Point 6, G adjustment value
7 GAMMA WRITE WB adjustment data writing
8 GAMMA RESET WB adjustment data reading
13 [M GAMMA6 B]
1 MONITOR B GAMMA 1 WB adjustment Point 1, B adjustment value Parameter for six-point adjustment
2 MONITOR B GAMMA 2 WB adjustment Point 2, B adjustment value
3 MONITOR B GAMMA 3 WB adjustment Point 3, B adjustment value
4 MONITOR B GAMMA 4 WB adjustment Point 4, B adjustment value
5 MONITOR B GAMMA 5 WB adjustment Point 5, B adjustment value
6 MONITOR B GAMMA 6 WB adjustment Point 6, B adjustment value
7 GAMMA WRITE WB adjustment data writing
8 GAMMA RESET WB adjustment data reading
14 [SOUND 1]
1 AUDIO SW
2 NOISE SIN
3 INPUT TRIM SP
4 INPUT TRIM HP
5 IN OUT
6 PINK SIN
7 SIN
8 CLIPPER LEVEL
9 ANGLE
15 [SOUND 2]
1 DOLBY MASTER VOLUME
2 SCART PRESCALE
3 FM AM PRESCALE
4 I2S1 PRESCALE
5 SCART1 VOLUME
