54
LC-45GD5U
TROUBLE SHOOTING TABLE (Continued)
NO
NO
NO
NO
NO
Are signals supplied from DVI
(SC1900) connector to IC1901?
Are signals supplied from DVI
(SC1900) connector to input
terminals RGB (pins 1, 3 and 5) and
H.Vsync (pins 1 and 3) of IC1904?
YES
Check PC settings.
YES
Check IC1915 and its
peripheral circuits.
YES
Check IC1917 and its
peripheral circuits.
Check the I2C signal line (SCLB/SDAB) of pins (1)
and (2) of IC1917.
Check IC1904 and its
peripheral circuits.
Check IC1901, IC1903 and
their peripheral circuits.
YES
Is IC1915 (E2PROM)
accessed with I2C
when connecting to PC
and is data read out?
Is IC1911 (E2PROM)
accessed with I2C
when connecting to PC
and is data read out?
NO
Are the output pins (12)
and (14) of IC1917
(E2PROM) in (H, L)?
Are the output pins (12)
and (14) of IC1917 in
(L, L)?
NO
Do the output pins (12)
and (14) of IC1917
change to (L, H) when
setting to the digital AV
mode?
Do the output pins (12)
and (14) of IC1917
change to (H, H) when
setting to the digital PC
mode?
Check MD harness for
disconnection.
NO
Are DVI_SR/SG/SB and DVI_H/V
signals supplied to pins (8), (17) and
(23) of IC3700 (A/D_CONV.) and pins
(3) and (13) of IC3701
(SYNC_SELECTER) respectively?
Check IC3700, IC3701
and their peripheral
circuits.
YES
Are there Vsync and Hsync signal
outputs at pins (4) and (6) of IC1904
(INVERTER)?
Are DVI_SR/SG/SB and DVI_H/V
signals sent from pins (14), (16), (18),
(30) and (31) of AV unit connector
(SC5701) respectively?
YES
Are DVI_SR/SG/SB and DVI_H/V
signals supplied to pins (20), (18),
(16), (4) and (3) of main PWB
connector (SC3201) respectively?
YES
No video signal from DVI input (analog) (2)
2 Tip HDCP_LSI
No video signal from analog PC No video signal from analog AV
To Next Page
