Using external equipment
VCR
AV cable
(commercially
available)
Connecting a VCR
You can use the INPUT 3 terminal when connecting a VCR and other audiovisual equipment.
Game console/Camcorder
S-video cable
(commercially
available)
Connecting a game console or camcorder
A game console, camcorder and some other audiovisual equipment are conveniently connected using the
INPUT 3 terminals.
NOTE
• The S-video terminal has priority over the video terminals.
• The G-LINK cable connection is necessary if you want to use the recording features of the TV Guide On Screen system
with your VCR.
AV cable
(commercially
available)
S-video cable
(commercially
available)
NOTE
• The S-video terminal has priority over the video terminals.
This connection is
necessary when
using TV Guide On
Screen’s recording
function.
(commercially
available)
(INPUT)(OUTPUT)
G-LINK cable
G-LINK
cable
This end is connected
to the TV.
1 inch
VCR
G-LINK wand
NOTE
• When attempting to record copy protected material on a VCR or other recording device, the copy protection will activate
and the protected material will not be recorded correctly. In addition, attempting to display copy protected material on a
monitor connected via a VCR, whether for the purpose of viewing or not, will cause an inferior quality picture to be
displayed. This is not a fault of the equipment. Please view copy protected material by connecting the product directly to
the monitor.
Using external equipment
Connecting a DVD player
You can use the INPUT 1, INP
UT 2, INPUT 4 or INPUT 5 terminals when connecting to a DVD player and other
audiovisual equipment.
NOTE
• For connecting a DVD player with HDMI terminal.
DVD player
Component
video cable
(commercially
available)
Audio cable
(commercially
available)
AV cable (commercially
available)
DVD player
ø 3.5 mm stereo minijack cable
(commercially available)
DVI cable (Commercially available)
When using component cable.
Wh
en using compos
ite cable.
When using DVI cable. (INPUT 5)
DVD player
To Next Page
