Quick guide
When you change the antenna connection
setting:
Press c/d to select “Change Setting” on the DVB-S
setting screen in the left column, and then press OK.
The antenna connection setting screen is displayed.
Single satellite
2 satellites on 22kHz switchbox
2 satellites on toneburst switchbox
Max. 4 satellites on DiSEqC multiswitch
Communal satellite system
NOTE
You can select the antenna connection method from the five types.
Consult your dealers before using a method other than “Single Satellite”.
“Single satellite” setting
Press a/b to select “Single satellite”, and then
press OK.
Press a/b to select “SAT1 [None]” to display
the satellite broadcasts that the TV can receive,
and then press OK.
SAT1 [None]
Next
Press a/b/c/d to select your favorite satellite,
and then press OK.
You cannot select “Next” unless you set the satellite
broadcast in step 3.
Press a/b to select “Next”, and then press OK.
ASTRA 1
ASTRA 3
Altalntic Bird 3
SAT1 [ASTRA 1]
Next
Press c/d to select “Yes (0/22kHz)” or “No” to
set the LNB frequency, and then press OK.
NoYes (0/22kHz)
Press a/b to select the item and press c/d to
adjust 9,000 MHz to 12,000 MHz to the
appropriate value.
o
•
•
E
1
2
3
•
4
5
6
EXAMPLE
SAT1 LOW [9000] 9000
9000
12000
12000
SAT1 High
OK
[12000]
Press a/b to select “OK”, and then press OK.
After completing this setting, the screen
switches to the DVB-S setting screen shown in
the left column on page 14.
7
15
