Connecting a PC
NOTE
The PC input terminals are DDC1/2B-compatible.
Refer to page 49 for a list of PC signals compatible with
the TV.
A Macintosh adaptor may be required for use with some
Macintosh computers.
When connecting to a PC, the input signal type is
automatically detected except 1,024 g 768 and 1,360 g
768 signals.
•
•
•
•
Analogue Connection
NOTE
Refer to page 38 for AV signals (See below).
HDMI: 480i/480p/576i/576p/720p/1080i/1080p
ANALOGUE RGB: 576p/720p (50Hz)/1080i
The ANALOGUE RGB terminal (PC) (EXT4) is not
compatible with 480i/576i/1080p signals.
•
•
Connecting a PC
HDMI Connection
Displaying a PC image on the
screen
Selecting the picture size
You can select the picture size.
Press f.
The “WIDE MODE” menu displays.
Press f or a/b to select a desired item on the
menu.
NOTE
Connect the PC before making adjustments.
Selectable picture size may vary with input signal type.
EXAMPLE
1
•
2
•
•
Full: An image fully fills the screen.
Cinema: For letterbox pictures. Bars may appear on the
top and bottom with some programmes.
Normal: Keeps the original aspect ratio in a full screen
display.
Dot by Dot: Displays an image with the same number of
pixels on the screen.
46
ø 3.5 mm stereo
minijack cable
HDMI1, 2 or 3
HDMI-certified cable
PC
HDMI1
DVI/HDMI cable
RGB cable
ø 3.5 mm stereo minijack cable
ø 3.5 mm stereo minijack cable
DVI/RGB conversion cable
Normal Full
Item
PC
EXT4
PC
EXT4
PC
