LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
3 – 1
LC-60EQ10U
Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS
Unit: inch (mm)
Unité: pouce (mm)
Unidad: pulgada (mm)
LC-60SQ17U/LC-60SQ15U/LC-60SQ10U/LC-60EQ10U
*1 Active area/Área activa/Zone active
*2 Thinnest part/Parte más delgada/Partie la plus mince
*3 Including projecting parts/Incluyendo partes salientes/Parties saillantes incluses
