LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
4 – 4
3. Removing of Connectors
1. Disconnect the following connectors from the MAIN Unit. (PD, LW, UB, BT,RA)
2. Disconnect the following connectors from the POWER/DRIVE Unit. (PD, LA)
3. Disconnect the following connectors from the LCD CONTROL Unit. (PL, LW)
䎰䎤䎬䎱䎃䎸䏑䏌䏗
[BT]
[UB]
[RA]
[LW]
[PD]
[PD]
[LA]
[LW]
[PL]
To Next Page
