LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
i
LC-60EQ10U
Service Manual
OUTLINE
OUTLINE
• We inform you that service parts in the PWB Unit.
NOTE: *1 Replace MAIN PWB Units (DKEYMG381FM01) in case of IC3103 failure.
Replace MAIN PWB Units (DKEYMG382FM01) in case of IC3103, IC3301 failure.
*2 Replace LCD CONTROL Units (DUNTKG400FM**) in case of IC5803 failure.
MODEL NAME PARTS CODE DESCRIPTION
LC-60/70EQ10U DKEYMG381FM01 MAIN Unit
LC-60/70SQ15U/17U,TQ15U,SQ10U,UQ17U DKEYMG382FM01 MAIN Unit
LC-60EQ10U,SQ10U/15U/17U DUNTKG400FM01 LCD CONTROL (T-CON) Unit
LC-70EQ10U,SQ10U/15U/17U DUNTKG400FM02 LCD CONTROL (T-CON) Unit
LC-60TQ15U,UQ17U DUNTKG400FM10 LCD CONTROL (T-CON) Unit
LC-70TQ15U,UQ17U DUNTKG400FM11 LCD CONTROL (T-CON) Unit
