Sharp LC-60LX650H User Manual

13
Preparation
H
LC-60LX650H
1
3
2
②
①
①
TOP-MIDDLE
FRONT
③
Softcushion
NOTE
•Wheninstallingthestand,youneedtoputyourTVonaat
surface.Beforethat,putasoft cushion on the surface.
•Theangleofthestandisnotadjustable.
•Todetachthestandunit,performthestepsinreverse
order.
•Ascrewdriverisnotsuppliedwiththisproduct.
•Duringinstallation,pleasebecarefultoavoidgettingyour
handtrappedbetweentheTVbottomandthefloor.
Insert the base into the slot on the bottom
of the TV(while holding the base to avoid it
falling over).
Insert the four screws into the four holes on
the back of the TV, and tighten them.
1
Insert the supporting post into the foam
blocks TOP-MIDDLE, as shown in the
figure below.
2
As illustrated in the following figure,
attach the supporting post onto the stand.
3
Insert the eight screws into the eight
holes on the bottom of the stand, and
tighten them.
•
To install the stand correctly, hold the stand
with one hand securely, and tighten the
screws with the other hand.
