Preparation
TV (Rear)
D-TV(Digital
antenna) terminal
HDMI2terminal
A-TV(Analogue
antenna) terminal
USB3(HDD)terminal*
4
LANterminal
Regarding the headphone jack
• Useheadphoneswithastereominiplug(Ø3.5mm).
• Besuretounplugheadphonesfromthejackwhentheyarenot
in use.
• Thespeakersdonotoutputvolumewhenheadphonesare
plugged in.
• The“Audio”menucannotbeoperatedwhenheadphonesare
plugged in.
• Youcansetthevolumetodifferentlevelsforeachinputsource.
Volume display when headphones are plugged in
30
Headphone/AUDIO
(R/L)terminal
HDMI3terminal
DIGITALAUDIO
OUTPUTterminal
HDMI1
terminal(ARC)*
1
HDMI4/MHL
terminal*
2
HDMI2/
PC AUDIO
INPUT
(
R
/L )terminal*
3
PCterminal
USB1terminal
USB2terminal
*1 Audio Return Channel ( ARC )
(Seepage66.)
*2
Mobile High-Definition Link (MHL)
can also be used.
(Seepage
69.)
*3
The
HDMI 2/ PC AUDIO INPUT
(
L
/R )
terminal
share the same
audioinputterminal(HDMI2/
PC
).However,theproperitemmust
beselectedinthe“Audioselect”menu.(Seepages62and71.)
*4
UsethisterminaliftherechargingoftheUSBHDDisbyUSB.
INPUT5
(COMPONENT/AUDIO)terminal
INPUT7
(VIDEO/AUDIO)terminal
RS-232Cterminal
INPUT6
(VIDEO/AUDIO)terminal
