Sharp LC-60LX650H User Manual

21
HDMI OUT
HDMI
IN
HDMI
OUT
Preparation
Using digital audio output
Itispossibletooutputaudiothroughthe
DIGITAL
AUDIO OUTPUT
terminal.PCMorBitstream(Dolbyor
DTSDigitalaudio)outputsfromtheterminal.
Connecting to the Network
Seepages76to77.
To optical digital input of external audio devices
Optical
brecable
(commercially
available)
NOTE
• TheDIGITALAUDIOOUTPUTterminalusuallyoutputsthe
same audio from the speakers. (The audio of the content
youareviewingisoutputfromtheterminal.)
• TheDIGITALAUDIOOUTPUTterminaldoesnotoutput
somesignals,dependingondevicesandsoftware.
Connecting a USB hard disk drive (HDD)
YoucanuseUSB3(HDD)terminalwhenconnectingaUSB
harddiskdrive.
USB hard disk drive
Connecting an AV amplifier
Set Top Box (STB)
HDMI-certiedcable
(commerciallyavailable)
NOTE
• Iftheimageisnotinsyncwiththeaudio,checkthesettings
of the connected surround system.
• LettingtheTVoutputtheaudiotoanAVamplier:
- WhenyouconnectARC-compatibleequipment,usethe
HDMI1terminal.
- Iftheequipmenttobeconnectedisnotcompatiblewith
theARC,connectanopticalbrecable.
When using RGB cable (commercially
available) connecting to a PC (see page 70 )
NOTE
•
Macintosh adaptor may be required for use for some
Macintosh computers.
When using HDMI cable (commercially
available)
Digital TV STB/VCR/
Game console/
Camcorder/DVD Player
•
WhenusingaDVI-HDMIadaptor,inputtheaudiosignal
fromtheHDMI2/
PC AUDIO INPUT
terminal.(Seepage71.)
•
Somecommerciallyavailabledevicesmayhavenotbeen
properlycertied.WhentheyareconnectedtotheTV
viaHDMI1,theremaybenosoundatall.Inthiscase,it
isrecommendedtouseHDMI2andHDMI2/PCAUDIO
INPUTterminaltoinputaudiosignals.
NOTE
PC
8
