Sharp LC-65LE654U User Manual

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
IR
IR_Power
+5V0
+5V0
+5V0
+5V0
0805/X7R
M= METAL 1%
NOTE : NC MEANS "NOT CONNECTED ON PCB BOARD"
ALL RESISTORS 25 VOLT IN .1uF UNLESS NOTED.
ALL RESISTORS VALUES IN OHMS UNLESS NOTED.
ALL CAPACITOR VALUES IN uF UNLESS NOTED.
ALL RESISTORS 1/10 WATT,5% UNLESS NOTED.
ALL CAPACITORS 50 VOLT & 105"C UNLESS NOTED.
ME request change from DIP 2.0 180 degree to DIP 1.25 90 degree
CR6
0.1uF/16V
CR6
0.1uF/16V
RR1 180RR1 180
UR1
FM-A438FN-5CN
UR1
FM-A438FN-5CN
Vout
3
GND
1
GND
2
VCC
4
CR5 0.1uF/16VCR5 0.1uF/16V
LED1
LED WHITE M02-0603QZD
LED1
LED WHITE M02-0603QZD
STM
JR2
1R25S_1X4ML
STM
JR2
1R25S_1X4ML
1
2
3
4
LR1 47LR1 47
DR1
NC/BAV99
DR1
NC/BAV99
1 2
3
CR1
10uF/16V
CR1
10uF/16V
DR2
NC/BAV99
DR2
NC/BAV99
1 2
3
CR7
100pF/16V
CR7
100pF/16V
CR4
NC/0.1uF/16V
CR4
NC/0.1uF/16V

Sharp LC-65LE654U Specifications

General

Brand	Sharp
Model	LC-65LE654U
Category	LCD TV
Language	English
