Sharp LC-65LE654U - Chapter 6 Main Board I;O Connections; JP1 Power Board to Main BD; J13 Main BD to IR BD Connection; JI3 Main BD to Display BD Connection

CONFIDENTIAL – DO NOT COPY
Page 6-1
File No. SG-0000351
Chapter 6 Main Board I/O Connections
JP1 CONNECTION [Power Board to Main BD]
Pin Description
1 PWR_19V
2 PWR_19V
3 PWR_19V
4 GND
5 GND
6 GND
7 +12V_ON_OFF
8 BL_ON_OFF
9 BL_DIMMING1
10 BL_DIMMING2
J13 CONNECTION [MAIN BD TO IR BD]
Pin Description
1 IR
2 IR_Power
3 GND
4 WHITE_LED
5 LS_SCL
6 LS_SDA
JI3
CONNECTION [MAIN BD TO DISPLAY BD]
Pin Description
1 IR_Power
2 GND
3 ADIN1
4 ADIN0
