Sharp LC-65LE654U - Chapter 13 Spare Parts List; Spare Parts Listing

CONFIDENTIAL – DO NOT COPY
Page 13-1
File No. SG-0000351
Chapter 13 Spare Parts List
Child P/N
Specification
Qty
Circuit Number
M/S
9LE
018467510083
POLYSWITCH 0.75A 8V SMD
(1206L075THYR) HF
1
FU5
M
9LE
018467510084
POLYSWITCH 0.75A 8V SMD
(KMC3S075RY006) HF
1
FU5
S
9LE
028027000213
X'TAL 27MHZ HC-49S 30PPM 20PF
18ohm + W/O PAD -20~85'C HF
2
Y1,YM2
9LE
045120000406
WAFER 2.0mm 4P 180' DIP KINK
(M24264) HF
2
J1,JI3
M
9LE
045120030403
WAFER 2.00mm 4P 180' KINK
(A2001WV2-4P) L-F
2
J1,JI3
S
9LE
045112500486
WAFER 1.25mm 4P 180' SMD
(MS24014) L-F
1
JM2
9LE
045120000606
WAFER 2.0mm 6P 180' DIP KINK
(M24266) HF
1
J13
M
9LE
045120030603
WAFER 2.00mm 6P 180' KINK
(A2001WV2-6P) L-F
1
J13
S
9LE
045120001066
WAFER 2.0mm 10P 90' DIP KINK
(M242610R) HF
1
JP1
M
9LE
045120031063
WAFER 2.00mm 10P 90' KINK
(A2001WR2-10P) L-F
1
JP1
S
9LE
045125000446
WAFER 2.5mm 4P 90' DIP KINK
(M241854R) L-F
1
JA1
M
9LE
045125000443
WAFER 2.50mm 4P 90' KINK
(A2501WR2-4P) L-F
1
JA1
S
9LE
045125000449
WAFER 2.50mm 4P 90' KINK
(A2501WR-04P1) L-F
1
JA1
S
9LE
030480000240
RJ45 CONN. 90' Without/LED
(5450-025-1G3-A9) LF
1
JN1
9LE
030062000051
USB CONN. A TYPE 90'
(UB1112C-4K5-4F) L-F
1
PU3
M
9LE
030062000130
USB CONN. A TYPE 90'
(3AL04S-305-ZC) L-F
1
PU3
S
9LE
030062000200
USB CONN. A TYPE 90'
(184-0420112-AT) LF
1
PU3
S
9LE
030064000070
OPTO CONN. Transmitter (JST1221)
L-F
1
PA1
M
9LE
030064000140
OPTO CONN. 90' Transmitter 16MB
(GQ48T-01) LF
1
PA1
S
9LE
030290200039
RCA JACK 1ROW 2I/O 90' (W-R)
(RCA215D-01) LF
1
PA2
M
9LE
030290200270
RCA JACK 1ROW 2I/O 90' (W-R)
(WT-04066V2B-06H) L-F
1
PA2
S
9LE
030290500049
RCA JACK 1ROW 5IO
90'(GBRWR)(RCA546D-01) LF
1
PV1
M
9LE
030290500071
RCA JACK 1R 5IO
90'(GBRWR)(WTJ-032-55V2B-01A) LF
1
PV1
S
9LE
030310023417
CONN B TO FPC 0.5mm 41P 90'
SMD(196334-41041-3) HF
1
JM5
9LE
030310023516
CONN B TO FPC 0.5mm 51P 90'
SMD(FBSNL05002N51) HF
1
JM4
M
9LE
030310023517
CONN B TO FPC 0.5mm 51P 90'
SMD(196334-51041-3) HF
1
JM4
S
9LE
030410000510
CONN HDMI 19P 90' SMD WITH
SPRING (1165-2CG04-24P) HF
3
PH4,PH5,PH6
