Chapter 14 Complete Parts List
LCD TV 65" LC-65LE654U_RTD2986iD (AUO T650HVN05.502)
Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
1 1 9LE 366500420334 BASE ASS'Y LC-65LE654U P Phantom EA 1
2 1 9LE 170105558010 BASE(ABS 94-HB/T52013)(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 171212001200 NECK SUPPORT_L(AL DIE CASTING)(LC-55LE653U) G Assembly Pull EA 1
2 1 9LE 171212001210 NECK SUPPORT_R(AL DIE CASTING)(LC-55LE653U) G Assembly Pull EA 1
2 51 9LE 172150030820 TAP. SCREW-TI M3.0*8.0L, Ni G Assembly Pull EA 12
2 1 9LE 172550030850 MAC. SCREW-MI M3.0*8.0L,BLK-NI, NYLOK G Assembly Pull EA 8
2 1 9LE 172550040720 MAC. SCREW MI M4.0*7.0L, Ni Nylok G Assembly Pull EA 8
2 61 9LE 172550041220 MAC. SCREW-MI M4.0*12.0L, Ni Nylok G Assembly Pull EA 12
2 1 9LE 181304032020 NECK BKT(SGCC 2.0t)(LC-65LE654U)ASS'Y G Assembly Pull EA 2
3 1 9LE 171201028650 NECK INNER(SGCC 2.0t)(LC-55LE653U) G Supplier EA 1
3 1 9LE 171304032020 NECK BKT(SGCC 2.0t)(LC-65LE654U) G Supplier EA 1
3 1 9LE 172530030850 MAC. SCREW-MF M3.0*8.0L,BLK-NI,NYLOK G Supplier EA 2
2 11 9LE 181304033010 BASE BKT_T(SGCC 1.0t)(LC-65LE654U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001190 FOOT PAD(SILICON/W18.0*L8.0*2.5t)(GRAY) G Supplier EA 2
3 1 9LE 171304033010 BASE BKT_T(SGCC 1.0t)(LC-65LE654U) G Supplier EA 1
2 21 9LE 181304034010 BASE BKT_B(SGCC 1.0t)(LC-65LE654U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001190 FOOT PAD(SILICON/W18.0*L8.0*2.5t)(GRAY) G Supplier EA 1
3 1 9LE 171304034010 BASE BKT_B(SGCC 1.0t)(LC-65LE654U) G Supplier EA 1
2 31 9LE 181304035010 BASE BKT_L(SGCC 2.5t)(LC-65LE654U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001190 FOOT PAD(SILICON/W18.0*L8.0*2.5t)(GRAY) G Supplier EA 2
3 1 9LE 171304035010 BASE BKT_L(SGCC 2.5t)(LC-65LE654U) G Supplier EA 1
2 41 9LE 181304036010 BASE BKT_R(SGCC 2.5t)(LC-65LE654U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001190 FOOT PAD(SILICON/W18.0*L8.0*2.5t)(GRAY) G Supplier EA 2
3 1 9LE 171304036010 BASE BKT_R(SGCC 2.5t)(LC-65LE654U) G Supplier EA 1
1 1 9LE 366501220315 MRO ASS'Y (SHARP LC-65LE654U) P Phantom EA 1
2 1 9LE 192519000860 TIE BAND(PP/L1600m*W12mm*0.7t)(WHITE) G Assembly Pull MZ 2.229
2 1 9LE 192521001741 CORNER BAR(L2000*40*40*4t) G Assembly Pull EA .333
2 1 9LE 192521003440 SLIP SHEET(L1140*W1760*0.9t/OPEN SIDE 1140) G Assembly Pull EA .084
2 1 9LE 192521003450 PAPER SHEET(L1700*W1100*8t) G Assembly Pull EA .084
2 1 9LE 193612000020 FG SHIPPING LBL(#80 art paper)(10cm x 18cm) G Assembly Pull EA .1667
2 1 9LE 193612000030 SHIPPING LBL(#80 art paper)(11cm x 7.5cm) G Assembly Pull EA .0834
2 1 9LE 193613002420 S/N LBL(#80 art paper)(55x15mm) G Assembly Pull EA 1
2 1 9LE 194712008460 CARTON TAPE(L600m*W72mm*0.06t) G Assembly Pull MZ 1.94
2 1 9LE 194725000660 PACKING FILM(L2000m*W500mm*0.0155t) G Assembly Pull MZ 3.762
1 1 9LE 366504920312 PACKING LC-65LE654U (AUO T650HVN05.502) P Phantom EA 1
2 1 9LE 192510018320 EPS FOAM FRONT(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 192510018330 EPS FOAM_TL(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 192510018340 EPS FOAM_TR(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 192510018350 EPS FOAM_BL(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 192510018360 EPS FOAM_BR(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 192511004980 EPE BAG(W1600*L1000*0.3t)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192511004990 PE BAG(W700*L500*0.06t)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192512023290 CARTON TRAY(W1712*H180*D170)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192512024780 CARTON(AB/FLUTE) Sharp LC-65LE654U G Assembly Pull EA 1
2 1 9LE 192517000210 CARTON JOINT(TM-32)(BLACK) G Assembly Pull EA 4
2 1 9LE 192521003620 PAPER SHEET(L395*W370*8t) G Assembly Pull EA 1
2 1 9LE 193611017650 B/C LBL(PET 50#)Sharp LC-65LE654U-A (AUO) G Assembly Pull EA 1
2 1 9LE 193613002500 S/N LBL(Black) 40*8(PET 50#) G Assembly Pull EA 1
Child P/N
Confidential-do not copy
Page 14-1
File No. SG-0000351
