CONFIDENTIAL – DO NOT COPY
Page 7-7
File No. SG-0000351
■ Basics
Single 27MHz crystal or OSC clock input with embedded PLLs.
Low power MCU available for standby mode control
1.05V core power, 3.3V analog power, 3.3V digital IO power and 1.5V DDR3 power
176pin TQFP-ePAD package
Electrical Characteristics
Recommended Operating Conditions
Parameter Symbol Min Typ Max Units
3.3V Supply Voltages VVDD_33 3.13 3.3 3.47 V
1.5V Supply Voltages VVDD 15 1.42 1.5 1.58 V
1.15V Supply Voltages VVDD_115 1.115 1.15 1.185 V
Ambient Operating Temperature TA 0 70 °C
Junction Temperature TJ 125 °C
Absolute Maximum Ratings
Parameter Symbol Min Typ Max Units
3.3V Supply Voltages VVDD_33
3.47 V
1.8V Supply Voltages VVDD 15
1.65 V
1.15V Supply Voltages VVDD_115
1.185 V
Storage Temperature TSTG -55 125 °C
