LC-90LE740X
5 – 6
5/20
1 HDMI CEC TEST Enter HDMI CEC test
2 HDMI EDID WRITE Enter HDMI EDID WRITING
3 INSPECT USB TERM PORT ALL : - - - - - - Reading inspection of USB memory terminal
4 MONIDATA READ [TEMP/OPC] OFF MONITOR Temperature/OPC Acquisition tool.
5 CAUSE RESET Enter Reset of standby cause
6/20
1 COMP15K ALL ADJ Enter Component 15K picture level adjustment
2 COMP15K MAIN Y GAIN 140 Y GAIN adjustment value
3 COMP15K MAIN CB GAIN 150 Cb GAIN adjustment value
4 COMP15K MAIN CR GAIN 150 Cr GAIN adjustment value
5 COMP15K Y OFFSET 64 Y OFFSET adjustment value
6 COMP15K CB OFFSET 128 CB OFFSET adjustment value
7 COMP15K CR OFFSET 128 CR OFFSET adjustment value
8 COMP15K A_CLAMP 0
7/20
1 HDTV ADJ Enter HDTV video level adjustment
2 HDTV Y GAIN 140 HDTV Y GAIN adjustment value
3 HDTV CB GAIN 150 HDTV Cb GAIN adjustment value
4 HDTV CR GAIN 150 HDTV Cr GAIN adjustment value
5 HDTV Y OFFSET 64 HDTV Y OFFSET adjustment value
6 HDTV CB OFFSET 128 HDTV CB OFFSET adjustment value
7 HDTV CR OFFSET 128 HDTV CR OFFSET adjustment value
8 HDTV A_CLAMP 0
8/20
1 ANALOG PC ADJ Enter DVI ANALOG video level adjustment
2 R OFFSET 64 R CUTOFF adjustment value
3 G OFFSET 64 G CUTOFF adjustment value
4 B OFFSET 64 B CUTOFF adjustment value
5 R GAIN 44 R DRIVE adjustment value
6 G GAIN 44 G DRIVE adjustment value
7 B GAIN 44 B DRIVE adjustment value
8 RGB A_CLAMP 0
9/20
1 VCOM ADJ 64 Common bias adjustment
10/20
1 DDR2 CHECK Enter Execute DDR check
2 BA[1:0] 0x00
3 ADDR[13:0] 0x0000
4 DQ[15:0] 0x0000
5 FRC ON/OFF Enter Execute FRC ON/OFF
11/20
1 R GAIN (LO) 0 R DRIVE adjustment value
2 G GAIN (LO) 0 G DRIVE adjustment value
3 B GAIN (LO) 0 B DRIVE adjustment value
4 R GAIN (HI) 0 R DRIVE adjustment value
5 G GAIN (HI) 0 G DRIVE adjustment value
6 B GAIN (HI) 0 B DRIVE adjustment value
12/20
1 MONITOR TIME OUT ON Monitor and the main communication time-out setting
2 MONITOR MAX TEMP 59 MONITOR MAX temperature setting
3 MONITOR EEP READ/WRITE WRITE MONITOR EEPROM READ/WRITE Setting/execution
4 MONITOR EEP ADR 0x 0 MONITOR EEPROM arbitrary addressing
5 MONITOR EEP DATA 0x 0 MONITOR EEPROM arbitrary data specification
13/20
1 LCD TEST PATTERN
2 LCD TEST PATTERN 1 NOT SUPPORT Pattern with built-in LCD controler display
3 LCD TEST PATTERN 2 OFF
4 LCD TEST PATTERN 3 NOT SUPPORT
5 LCD TEST PATTERN 4 NOT SUPPORT
Page Line Item Description Remarks (adjustment detail, etc.)
To Next Page
