Sharp LMV Series User Manual

44
NO.
PART NO.
DESCRIPTION
SPECIFICATION
Q'TY
1
L-C271
Body
1
2
1500-C125
Back cover
1
3
HCAP-M06015
Hex-Soket Head Cap Screw
M6× 15
4
5
1500-C130
Filter Oil Net
2
6
HCAP-M05010
Hex-Soket Head Cap Screw
M5 × 10
4
7
1500-C170B
Level Screw And Nut
4
8
HBBE-W070
Nut
W7/8*32*18
4
9
1800-C146
Leveling Pads
4
10
1500-C103
Elevating Screw Housing
1
11
1500-C139
Elevating Screw Nut(Metric)
1
12
HCAP-M06020
Hex-Soket Head Cap Screw
M6 × 20
6
13
J2-0309
Nozzle
1/8PT
1
14
1500-C175
Knee
1
15
1500-C061
Chip Guards (Down)
1
16
1500-C060A
Chip Guards (Up)
1
17
1500-C069
Knee Lock Plunger
2
18
1500-C037
Table Lock Bolt Handle
4
19
1500-C044
Gear Shaft Clutch Insert
1
20
HADA-W10141
Cross-Recessed Head Screw
3/16 ×15
2
21
1500-C055
Knee Column Gib
1
22
1500-C041A
Adjusting Screw
2
24
1500-C044
Felt Wipers
1
25
HBBE-W031
Nut
1/2"
1
26
1500-C076
Washer
5
27
1500-C077
Bevel Gear (Big)
1
28
BR-6205
Bearing
6205
1
29
BR-51305
Bearing
51305
1
30
HKE-2R-5515
Flat Key
5×5×15
2
31
1500-C137
Elevating Screw (Metric)
1
32
1500-C096
Bevel Gear(Small)
1
33
HSET-M06010
Set Screw
M6×10
1
34
BR-6204
Bearing
6204
2
35
HKE-2R-5550
Flat Key
4×4×20
1
36
1500-C094
Elevating Shaft
1
37
1500-C092
Bearing Housing
1
38
1500-C090
Bearing Cap
1
