45
39
1500-C088
Dial Holder
1
40
1500-C138
Dial With 125 Graduation(Metric)
1
41
1500-D006
Dial Nut
1
42
1500-C085
Gear Shaft Clutch Insert
1
43
1500-C084
Elevating Crank
1
44
1500-C083
Ball Crank Handle Lever
1
45
1500-C118
Spider
1
46
1500-C124
Turret
1
47
1500-C111
Turret-Ram Gib
1
48
1500-C127
Locking Bolt
4
49
1500-C128
Ram Pinion Set
1
50
1500-C110
Gib Lock Screw
2
51
HWS-3/8
Nut
3/8"
2
52
1500-C126
Ram Lock Plunger
2
53
1500-C120
Ram Pinion
1
54
N1500-C048
Turret scale
1
55
Ø 2×5
Small Rivet Nut
Ø 2×5
8
56
N1500-C144
Zeroing Point Plate
1
58
N1500-C015
Angle Plate
1
59
1500-C017
Adaptor Pivot Stud
1
60
HSTW-S28
Snap Ring C-Type
S-28
2
61
L-C473
Adaptor Locking Bolt
6
62
HWA-1/2
Washer
1/2"
6
63
HWS-1/2
Nut
1/2"
6
64
L-C224
Ram
1
65
1500-C011
Hook
1
66
1500-C008
Vertical Adjusting Worm Shaft
1
67
HKE-2R-5550
Flat Key
5×5×50
1
68
1500-C012
Worm Thrust Washer
1
69
1500-C006
Vertical Adjusting Worm
1
70
1500-C007
Washer
1
71
L-C225
Ram Adaptor
1
72
N1500-C003
Adaptor Scale
1
73
1500-C001
Quill Housing Adjusting Gear
1
74
HAEC-W025112
Hex-Soket Head Cap Screw
5/16×11/2
2
75
HPB-0830
Overload Clutch Lever Spring Plunger
Ø 8×30
1
76
HCAP-M05010
Hex-Soket Head Cap Screw
M10 × 20
2
