Sharp LMV Series User Manual

48
NO.
PART NO.
DESCRIPTION
SPECIFICATION
Q'TY
1
1500-B192
Milling Head
1
2
L-H166
Spindle
1
3
1500-B026
Stop Block
2
4
5/16"x5/8"
Hex Socket Head Cap Screw
5/16"x5/8"
2
5
1500-B194
Nut
NT30
1
L-H172
Nut
R8
1
6
1500-B134
Spindle Dirt Shield
1
7
BR-7207
Bearing
7207
2
8
1500-B137
Bearing Spacer (Large)
1
9
1500-B136
Bearing Spacer (Large)
1
10
L-H176
Sleeve
1
11
BR-6206
Bearing
6206
1
12
AW06-30MM
Lock Washer
AW-06
1
13
1500-B129
Locknut Washer
(M30)
1
14
L-H167
Quill
1
15
HSET-M05005
Set Screw
M5×5
2
16
1500-B151
1
17
HWA-M5
Washer
M5
1
18
HCAP-M05010
Hex Socket Head Cap Screw
M5×10
2
19
1500-B128
Quill Skirt
1
20
1500-B166
Quill Pinion Shaft
1
21
1500-B168
Pin
1
22
HKE-2R-3318
Flat Key
3×3×18
1
23
1500-B178
Clock Spring
1
24
1500-B177
Spring Cover
1
25
HCAP-M05012
Hex Socket Head Cap Screw
M5×12
2
26
1500-B176A
Pinion Shaft Hub Sleeve
1
27
1500-B175
Back Feed Handle Hub (Quill Feed Lever)
1
28
HPB-0516
Overload Clutch Lever Spring Plunger
Ø 5×16"
1
29
HETC-W015
Steel Ball
3/16"
1
30
1500-B174
Compression Spring
1
31
HSET-W025030
Set Screw
5/16"×3/8"
1
32
1500-B190
Pinion Shaft Hub Handle
1
33
1500-B191
Black Plastic Ball
3/8"
1
34
1500-B172
Pinion Shaft Hub Screw
1
35
1500-B090
Quill Pinion Shaft Bushing
1
