Sharp LMV Series User Manual

49
36
1500-B091
Washer
1
37
1500-B092+B093
Overload Clutch Worm Gear
1
38
HSTW-S15
Snap Ring C-Type
S-15
1
39
1500-B081
Over Load Clutch
1
40
1500-B080
Overload Clutch
1
41
1800-B079
Safety Clutch Spring
1
42
1500-B078
Overload Clutch Locknut
1
43
HSET-M05005
Set Screw
M5×5
1
44
1500-B075
Clutch Ring
1
45
1500-B096
Overload Clutch Trip Lever
1
46
1500-B074
Clutch Ring Pin
2
47
HPB-0518
Overload Clutch Lever Spring Plunger
Ø 5×18
1
48
1500-B097
Overload Clutch Washer
1
49
HSTW-S10
Snap Ring C-Type
S-10
1
50
1500-B099
Clutch Arm Cover
1
51
HSET-W020060
Set Screw
1/4"×3/4"
1
52
HBBA-W020
Nut
1/4"
1
53
HCAP-M05035
Hex Socket Head Cap Screw
M5×35
2
54
1500-B042
Bushing
1
55
1500-B057
Feed Worm Shaft
1
56
HKE-2R-3315
Flat Key
3×3×15
1
57
HKE-2R-3310
Flat Key
3×3×10
1
58
1500-B044
Feed Worm Shaft Bushing
1
59
1500-B047
Feed Worm Shaft Thrust Washer
1
60
HSTW-S12
Snap Ring C-Type
S-12
1
61
1500-B049
Feed Reverse Bevel Gear
2
62
1500-B050
Feed Reverse Clutch
1
63
HPB-0312
Overload Clutch Lever Spring Plunger
Ø 3×20
1
64
1500-B055
Reverse Clutch Rod
1
65
L-H017
Feed Trip Bracket
1
66
HCAP-M06020
Hex Socket Head Cap Screw
M6×20
2
67
1500-B118
Cam Rod Sleeve Assembly
1
Spring
1500-B120
1
Trip Plunger
1500-B121
1
HPB-0312
Overload Clutch Lever Spring Plunger
Ø 3×12
1
HPB-0314
Overload Clutch Lever Spring Plunger
Ø 3×14
1
Cam Rod
1500-B103
1
