NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-C2
SWD26 92LSWICHT1663T J AC Switch,Key Type
[TUNER (BAND)]
SWD27 92LSWICHT1663T J AC Switch,Key Type [TAPE]
SWD28 92LSWICHT1663T J AC Switch,Key Type [MD 1]
SWD29 92LSWICHT1663T J AC Switch,Key Type [MD 2]
SWD30 92LSWICHT1663T J AC Switch,Key Type [MD 3]
SWD31 92LSWICHT1663T J AC Switch,Key Type
[REW/TUNING DOWN]
SWD32 92LSWICHT1663T J AC Switch,Key Type [STOP]
SWD33 92LSWICHT1663T J AC Switch,Key Type
[DELETE/CLEAR]
SWD34 92LSWICHT1663T J AC Switch,Key Type
[NAME/TOC EDIT]
SWD35 92LSWICHT1663T J AC Switch,Key Type [PROGRAM]
SWD37 92LSWICHT1663T J AC Switch,Key Type [CD>MD EDIT]
SWD38 92LSWICHT1663T J AC Switch,Key Type [PLAY MODE]
SWD39 92LSWICHT1663T J AC Switch,Key Type [DISPLAY]
SWD40 92LSWICHT1663T J AC Switch,Key Type
[FF/TUNING UP]
SWD41 92LSWICHT1663T J AC Switch,Key Type [PLAY/PAUSE]
SWD42 92LSWICHT1663T J AC Switch,Key Type [ENTER]
SWD43 92LSWICHT1663T J AC Switch,Key Type [AUX]
SWD44 92LSWICHT1663T J AC Switch,Key Type [CD]
SWF02 QSW-S0024AWZZ J AE Switch,Slide Type [DEMO]
SWK00 92LM-SW1676A J AC Switch,Leaf Type [F.P]
SWK01 92LM-SW1658A J AB Switch,Leaf Type [CAM]
WTV00 92LCONE5P52287 J AC Plug,5Pin
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion,Keep off Vibration,Gray
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit (Not
Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
MK02 92LMTR2790CASY J BB Motor with Chassis [Spindle]
MK03 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
MD MECHANISM PARTS
1 LANGF0041AWZZ J AE MD Guide M
2 LANGF0042AWZZ J AE MD Guide S
3 LANGJ0008AWZZ J AD Joint Angle,Left
4 LANGJ0009AWZZ J AD Joint Angle,Right
5 LCHSM0077AWM1 J AU Chassis Ass’y,Main
6 LHLDX3002AWM1 J AU Holder Ass’y,Cartridge
7 MARMM0003AWM1 J AF Arm Ass’y,Roof Move Arm
8 MARMM0004AWZZ J AD Arm,H/A Shift
9 MARMM0005AWM1 J AE Arm,Ass’y,Clamp
10 MCAMP0008AWZZ J AD Cam,Main
11 MLEVF0031AWM1 J AM Roof Lever Ass’y
12 MLEVF0032AWM1 J AF Lever Ass’y,Switch
13 MLEVF0038AWM1 J AG Lever Ass’y,Catch Joint
14 MLEVF0039AWZZ J Lever,Catch
15 MLEVP0088AWZZ J AC Lever,Clamp Push
16 MSLIP0001AWZZ J AH Slider
17 MSPRD0116AWFJ J AB Spring,Spin
18 MSPRD0117AWFJ J AB Spring,Roof Arm
19 MSPRD0118AWFJ J AB Spring,Clamp Gear
20 MSPRD0120AWFJ J AB Spring,Clamp Push
21 MSPRP0015AWFJ J AB Spring,PA
22 MSPRP0017AWFJ J AB Spring,Drive Shaft
23 MSPRT0024AWFJ J AC Spring,H/A Shift Arm
24 MSPRT0025AWFJ J AC Spring,Clamp Arm
25 MSPRT0026AWFJ J AC Spring,Holder
27 NGERH0074AWZZ J AD Gear,B,Idler
28 NGERH0075AWZZ J AD Gear,C,Idler
29 NGERH0076AWZZ J AD Gear,Cam Idler
30 NGERH0077AWZZ J AE Gear,Clamp
31 NGERH0083AWZZ J AE Gear,A,Idler
32 NROLM0002AWFW J AD Roller,Slider
33 NSFTD0005AWM1 J AF Screw Ass’y,Drive
34 NSFTM0277AFFW J AC Shaft,Pickup Slide
(Pick Guide Shaft (A))
35 NSFTM0278AFFW J AC Shaft,Pickup Slide
(Pick Guide Shaft (B))
36 NSFTT0035AWFW J AD Shaft,Slider
37 RCILH0111AFZZ J AN Magnet Head
38 RCTRH8190AFZZ J BL MD Optical Pickup Ass’y
401 LX-BZ0030AWZZ J AB Screw,ø1.7×9.5mm
402 LX-BZ0031AWZZ J AB Screw,ø1.7×7.5mm
403 LX-BZ0032AWZZ J AB Screw,ø1.7×2mm
404 LX-BZ0036AWZZ J AC Screw,ø1.7×2.1mm
405 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
406 LX-BZ0835AFZZ J AB Screw,ø1.7×2.5mm
407 LX-BZ0846AFZZ J AB Screw,ø1.7×3mm
408 LX-BZ0851AFZZ J AB Screw,ø1.7×2.5mm
409 LX-WZ9031AWZZ J AB Washer,ø1.4×3.2×0.25mm
410 LX-WZ9032AWZZ J AC Washer,ø1.2×3×0.3mm
411 LX-WZ9183AFZZ J AA Washer,ø1×4×0.25mm
412 LX-WZ9268AFZZ J AA Washer,ø1.5×ø3.2×0.5mm
CW1903 QCNWN1454AWZZ J AD Flat Cable,6Pin
M1951 RMOTV0019AWZZ J AX MD Spindle Motor Ass’y
M1952 92LMTR3011AASY J AX MD Loading Motor Ass’y
M1953 92LMTR3011BASY J AX MD Sled Motor Ass’y
SW1930 QSW-P0006AWZZ J AG Switch,Push Type [DISC ID]
SW1931 QSW-M0005AWZZ J AH Switch,Push Type [LEAD IN]
SW1932 QSW-M0166AFZZ J AD Switch,Push Type [PLAY]
SW1933 QSW-M0166AFZZ J AD Switch,Push Type [REC]
SW1934 QSW-M0166AFZZ J AD Switch,Push Type [UNLOAD]
SW1935 QSW-P0008AWZZ J AC Switch,Push Type [CARTRIDGE]
MD CHANGER MECHANISM PARTS
101 GCOVA1220AWZZ J AN Front Mask,MD Changer
102 LANGF0043AWZZ J AF Motor Angel
103 LCHSM0078AWZZ J AQ Base Plate
104 LCHSM0079AWZZ J AN Top Plate
105 LHLDZ1211AWZZ J AH Holder,MD Mechanism
106 LPLTM0007AWZZ J AD Plate,Eject Fixing
107 LPLTP0006AWZZ J AN Side Panel,MD Changer,Left
108 LPLTP0007AWZZ J AN Side Panel,MD Changer,Right
109 MARMM0006AWZZ J AG Arm,Lift
110 MARMP0006AWZZ J AD Arm,Eject
111 MARMP0007AWZZ J AC Arm,Reverse
112 MARMP0008AWZZ J AD Arm,Stopper
113 MARMP0009AWZZ J AC Arm,Click
114 MARMP0010AWZZ J AD Lid,MD Front
115 MLEVP0089AWM1 J AD Lever Ass’y,Lift
116 MLEVP0090AWZZ J AD Lever,Switch A
117 MLEVP0091AWZZ J AD Lever,Switch B
118 MSPRD0121AWFJ J AC Spring,Lift
119 MSPRD0122AWFJ J AB Spring,MD Front Lid
120 MSPRP0020AWFJ J AD Spring,Stopper
121 MSPRP0025AWFJ J AC Plate,Eject Spring
122 MSPRT0028AWFJ J AC Spring,Eject Arm
123 NGERH0079AWZZ J AG Gear,D,Idler
124 NGERH0080AWZZ J AE Gear,E,Idler
125 NGERH0081AWZZ J AE Gear,F,Idler
126 NSFTT0037AWFD J AE Shaft,Stopper Arm
127 PCUSG0040AWZZ J AC Cushion,Gom
128 PSHEF0010AWZZ J AB Sheet,Flat Cable
129 PSHEF0011AWZZ J AB Sheet,B,Flat Cable
130 92LN-BAND1318A J AA Nylon Band,80mm
501 LX-BZ0037AWFE J AD Screw Special,Cushion Gom
502 LX-BZ0846AFZZ J AB Screw,ø1.7×3mm
503 LX-EZ0019AWFF J AB Screw,ø1.7×4.5mm
504 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
505 XEBSD20P07000 J AB Screw,ø2×7mm
506 XHBSD20P03000 J AA Screw,ø2×3mm
507 XHBSD20P04000 J AA Screw,ø2×4mm
508 XHBSD20P05000 J AA Screw,ø2×5mm
509 XWSSD20-06000 J AA Washer,ø2×0.6mm
CW1501 QCNWN6768AFM1 J AU Flat Cable,28Pin
CW1911 QCNWN1446AWZZ J AK Flat Cable,24Pin
CW1921 QCNWN1447AWZZ J AC Flat Cable,12Pin
CW1940 QCNWN1448AWZZ J AC Flat Cable,7Pin
M1941 92LMTR3011CASY J AX MD Lift Motor Ass’y
SW1940 QSW-B9003AWZZ J AC Switch,Lever Type [SLOT 1]
SW1941 QSW-B9003AWZZ J AC Switch,Lever Type [SLOT 2]
SW1942 QSW-B9003AWZZ J AC Switch,Lever Type [SLOT 3]
SW1943 QSW-P0920AFZZ J AC Switch,Push Type [LIFT A]
SW1944 QSW-P0920AFZZ J AC Switch,Push Type [LIFT B]
– 8 –
