MD-C2
– 78 –
51* HI-VOLT P15 Output – L TUNER AM : "L"
52 V-LOAD2 P14 Output – L –
53 V-LOAD1 P13 Output – L "H" : 5V, "L" : 6.5V
54 POWER P12 Output – L STANDBY : "L", others : "H"
55 SP-RELAY P11 Output – L "H" : RELAY "ON"
56 FAN MOTOR P10 Output – L "H" : MOTOR "ON"
57* – P07 Output – – –
58* – P06 Output – – –
59* – P05 Output – – –
60* – P04 Output – – –
61* – P03 Output – L –
62* – P02 Output – L –
63* – P01 Output – L –
64* – P00 Output – L –
65 P. B. MUT P37 Output H L TAPE control
66 REC MUT P36 Output H L TAPE control
67 PB/REC P35 Output – L TAPE control
68 BIAS P34 Output – L TAPE control
69* BEET CUT P33 Output – L TAPE control
70 MOTOR P32 Output H L TAPE control
71 TAPE-SOL P31 Output H L TAPE control
72* – P30 Output – – –
73* – P97 Output – L –
74* – P96 Output – – –
75* – P95 Output – – –
76* – P94 Output – – –
77* – P93 Output – L –
78* – P92 Output – – –
79* – P91 Output – L –
80* – P90 Output – L –
81 RUN-PULSE P87 Input – – TAPE RUN-PULSE
82 FP-SW P86 Input – – Write-protection switch
83 CAM-SW P85 Input – – –
84 – P84 Input – – TUNER destination setting
85 – P83 Input – – TUNER destination setting
86 – P82 Input – – TUNER destination setting
87* ROM-DE P81 Output – L For sending and receiving RDS data storage memory
88* ROM-CK P80 Output – L For sending and receiving RDS data storage memory
89* ROM-DI PA7 Output – L For sending and receiving RDS data storage memory
90 ROM-DO PA6 Input – – For sending and receiving RDS data storage memory
91 – Vcc – – – –
92 DEMO/STAND PA5 Input – – "H" : STANDBY start
93* CD-HI PA4 Output – L CD double speed : "H"
94 UP/DN-SW PA3 Input L – CD changer detection SW
95 D NO-SW PA2 Input L – Disc number detection SW
96 OP/CL-SW PA1 Input L – Tray open/close detection SW
97 PU IN-SW PA0 Input L – Inner radius : "L"
98 Vee – – – – –
99 Arss – – – – –
100 Aref – – – – –
ICF01 RH-iX0265AW00:System Control Microcomputer (iX0265AW) (2/3)
Pin No.
Function
Terminal Name
Input/Output
Port Name
Active
Level
Setting
in Reset
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
