MX-C250 SIMULATION 6 – 52
50-22
Purpose
Adjustment
Function (Purpose)
Used to adjust the image registration. (Main
scan direction, sub scan direction) (Auto
adjustment)/OPC drum phase adjustment
(Auto adjustment)
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
NOTE: The contents of the following list are mainly used by the
technical division, and are not necessary for the market.
10 PAPER
Cassette selection
1:MFT(Manual paper feed),
2:CS1(Cassette1) 3:CS2(Cas-
sette 2)
1 - 3 2(CS1)
11
REGIST_SU
B_C
Registration adjustment value sub
scanning direction value CYAN
(Black Drum standard)
1 - 199 100
12
REGIST_MA
IN_C_F
Registration adjustment value
main scanning direction CYAN F
side
1 - 199 100
(Cyan laser writing position F
side)
1 - 199 100
13
REGIST_MA
IN_C_R
Registration adjustment value
main scanning direction CYAN R
side
1 - 199 100
(Cyan laser writing position R
side)
1 - 199 100
14
REGIST_SU
B_M
Registration adjustment value sub
scanning direction value Magenta
(Black Drum standard)
1 - 199 100
15
REGIST_MA
IN_M_F
Registration adjustment value
main scanning direction
MAGENTA F side
1 - 199 100
(Magenta laser writing position F
side)
1 - 199 100
16
REGIST_MA
IN_M_R
Registration adjustment value
main scanning direction
MAGENTA R side
1 - 199
100
(Magenta laser writing position R
side)
100
17
REGIST_SU
B_Y
Registration adjustment value sub
scanning direction value Yellow
(Black Drum standard)
1 - 199 100
18
REGIST_MA
IN_Y_F
Registration adjustment value
main scanning direction YELLOW
F side
1 - 199
100
(Yellow laser writing position F
side)
100
19
REGIST_MA
IN_Y_R
Registration adjustment value
main scanning direction YELLOW
R side
1 - 199 100
(Yellow laser writing position R
side)
1 - 199 100
20 PAPER
Cassette selection
1:MFT(Manual paper feed),
2:CS1(Cassette1) 3:CS2(Cas-
sette 2)
1 - 3 2(CS1)
Display/Item Content Display
SKEW_K
Print skew amount calculation result
(Cyan)
-99.9 - 99.9
SKEW_C
Print skew amount calculation result
(Cyan)
-999 - 999
SKEW_C(DIF)
Print skew amount calculation result
(Cyan) (Difference from the previous
adjustment value)
-1999 - 1999
Item/Display Contents Range
Default
value
SKEW_M
Print skew amount calculation result
(Magenta)
-999 - 999
SKEW_M(DIF)
Print skew amount calculation result
(Magenta) (Difference from the previ-
ous adjustment value)
-1999 - 1999
SKEW_Y
Print skew amount calculation result
(Yellow)
-999 - 999
SKEW_Y(DIF)
Print skew amount calculation result
(Yellow) (Difference from the previ-
ous adjustment value)
-1999 - 1999
REGIST_SUB_
C
Registration adjustment value sub
scanning direction (Cyan drum ->
Black drum)
1.0 - 199.0
REGIST_SUB_
C(DIF)
Registration adjustment value sub
scanning direction (Difference from
the previous adjustment value)
(Cyan drum to Black drum)
-199.9 - 199.9
REGISTMAIN_
C_F
Registration adjustment value main
scanning direction (Cyan laser writ-
ing position F side)
1.0 - 199.0
REGISTMAIN_
C_F(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value)
(Cyan laser writing position F side)
-199.9 - 199.9
REGISTMAIN_
C_R
Registration adjustment value main
scanning direction (Cyan laser writ-
ing position R side)
10 - 1990
REGISTMAIN_
C_R(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value)
(Cyan laser writing position R side)
-1999 - 1999
REGIST_SUB_
M
Registration adjustment value sub
scanning direction (Magenta drum ->
Black drum)
1.0 - 199.0
REGIST_SUB_
M(DIF)
Registration adjustment value sub
scanning direction (Difference from
the previous adjustment value)
(Magenta drum to Black drum)
-199.9 - 199.9
REGIST_MAIN_
M_F
Registration adjustment value main
scanning direction (Magenta laser
writing position F side)
1.0 - 199.0
REGIST_MAIN_
M_F(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value)
(Magenta laser writing position F
side)
-199.9 - 199.9
REGIST_MAIN_
M_R
Registration adjustment value main
scanning direction (Magenta laser
writing position R side)
10 - 1990
REGIST_MAIN_
M_R(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value)
(Magenta laser writing position R
side)
-1999 - 1999
REGIST_SUB_
Y
Registration adjustment value sub
scanning direction (Yellow drum ->
Black drum)
1.0 - 199.0
REGIST_SUB_
Y(DIF)
Registration adjustment value sub
scanning direction (Difference from
the previous adjustment value) (Yel-
low drum -> Black drum)
-199.9 - 199.9
REGIST_MAIN_
Y_F
Registration adjustment value main
scanning direction (Yellow laser writ-
ing position F side)
1.0 - 199.0
REGIST_MAIN_
Y_F(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value) (Yel-
low laser writing position F side)
-199.9 - 199.9
REGIST_MAIN_
Y_R
Registration adjustment value main
scanning direction (Yellow laser writ-
ing position R side)
1.0 - 199.0
REGIST_MAIN_
Y_R(DIF)
Registration adjustment value main
scanning direction (Difference from
the previous adjustment value) (Yel-
low laser writing position R side)
-1999 - 1999
PHASE
OPC drum phase adjustment value
(BK to CL)
0 - 359
PHASE before
OPC drum phase adjustment value
(BK to CL)
0 - 359
Display/Item Content Display
